Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Butted Aluminum for 27.5", Tapered Head Tube, Formed Top and Down Tube, w/ Integrated Disc Brake Tabs, Progressive Geometry, 148x12MM Thru-Axle for Maxxel
Suspension Fork
Rockshox Recon RL, Solo Air, 140mm Travel, 32mm Stanchions, 15mm Thru-axle, Tapered Steerer Tube, w/ Turn Key Lock out
Drivetrain
Rear Derailleur
SRAM SX 12 Speed
Shift Levers
SRAM SX Trigger 12 Speed
Cassette
SRAM SX 12 Speed 11-50T
Crank
SRAM SX Eagle w/ Steel 32T "Narrow Wide"
Bottom Bracket
Power Spline 73mm, 118mm Spindle
Chain
SRAM SX 12 Speed
Pedals
DB Alloy Platform w/ Replaceable Pins
Wheels
Front Hub
32h Alloy, 110x15mm Thru-axle, Sealed Cartridge Bearings, w/ CNC Disc Mount
Rear Hub
32h Alloy, Boost 148x12mm Thru-axle, 2 Sealed Cartridge Bearing, for SRAM XD w/ CNC Disc Mount
Rims
Diamondback AL35, Tubeless ready, 32h
Spokes
14g Stainless Steel
Tires
Vee Rubber Crown Gem 27.5x2.8
Brakes
Brakes
SRAM Level T Hydraulic Disc, w/ 180mm Front and 160mm Rear G2 Rotors
Brake Levers
SRAM Level T Hydraulic
Cockpit
Stem
Race Face Chester, 40mm Reach, 35 Bar Bore
Handlebar
Race Face Chester, 780mm Wide, 35 Bar Bore
Grips
New DB "Flanged" Lock-on, 135mm Silcone
Headset
FSA NO.57, Sealed Cartridge for Tapered Headtube
Seat
Saddle
DB Sync'r Saddle
Seatpost
JD YSP18JL, Dropper post with Remote 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.33 mm | 1.32 mm | 1.3 mm |
| Bottom Bracket Height | 317 mm | 317 mm | 317 mm | 317 mm |
| Front Center | 707 mm | 723 mm | 743 mm | 764 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 112 mm | 113 mm | 112 mm | 112 mm |
| Stack | 587 mm | 587 mm | 601 mm | 614 mm |
| Reach | 426 mm | 443 mm | 456 mm | 472 mm |
| Top Tube Length | 594 mm | 609 mm | 628 mm | 648 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 420 mm | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1139 mm | 1155 mm | 1175 mm | 1197 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 739 mm | 760 mm | 794 mm | 826 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Sync’r completes the Diamondback Syncr model. Diamondback released 19 bikes variations of this model so far. You can easily view all of the Diamondback Syncr bikes models from 2021, here.
Model range prices
Diamondback Sync’r 24 2021 is the cheapest bike model and costs 1000$. Diamondback Sync’r Carbon 29 2021 is the most expensive one and costs 3650$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2021 and its price was 1500$. Comparing the average cost of a Trail bike to this one, you will see that Sync’r price is 84.13% smaller.
Overview of components
Fork
This bike has the RockShox Recon Silver RL fork installed. The fork’s travel is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The Sync’r 2021 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sync’r comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Diamondback Sync’r bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Diamondback Sync’r comes with a dropper post. Therefore, climbing or descending will be a breeze.
