Ellsworth Truth Convert Shimano XTR 27.5″+ 2018
2018 Mountain
Estimate price |
8,295$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Fox Factory Float 32
-
Groupset XTR -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
100mm: FOX 32 Float 29 SC Factory, 130mm: FOX 34 Float 29 Factory, Kashima
Rear Shock
FOX Float DPS Factory
Drivetrain
Rear Derailleur
Shimano XTR 9000
Front Derailleur
N/A
Shift Levers
Shimano XTR 9000, 11-speed
Cassette
Shimano XTR, 11-42 tooth, 11-speed
Crank
Shimano XTR 9000, Boost, 175mm length
Bottom Bracket
Shimano BSA threaded
Chain
Shimano XTR 9000, 11-speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
DT Swiss M1700, Boost front and rear
Rear Hub
DT Swiss M1700, Boost front and rear
Rims
DT Swiss M1700, 35mm width
Spokes
DT Swiss
Tires
Maxxis Ikon, 27.5" x 2.8"
Brakes
Brakes
Shimano XTR 9020 with Shimano 180mm front/160mm rear Ice Tech rotors
Brake Levers
Shimano XTR
Cockpit
Stem
Race Face Turbine, 70mm length, 6mm rise, 31.8mm clamp
Handlebar
Race Face Next, 725mm width, 31.8mm diameter, 20mm rise
Grips
Lizard Skin Charger EHB
Headset
Cane Creek 10 Series ZS44/56
Seat
Saddle
WTB SL8 Team-Ti
Seatpost
FOX Transfer Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 327 mm | 327 mm | 327 mm |
| Stack | 583 mm | 592 mm | 602 mm |
| Reach | 418 mm | 443 mm | 467 mm |
| Top Tube Length | 570 mm | 598 mm | 625 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 98 mm | 109 mm | 120 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1116 mm | 1145 mm | 1174 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm |
| Standover Height | 627 mm | 627 mm | 627 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Truth Convert Shimano XTR 27.5″+ is part of the Ellsworth Truth model. 10 bikes variations carry this model name so far. You can easily view all of the Ellsworth Truth bikes models from 2018, here.
Model range prices
Ellsworth Truth Convert SRAM GX 27.5″+ 2018 is the most economical model, with a starting price of 6145$. Ellsworth Truth Convert SRAM XX1 Eagle 29″ 2018 on the other hand costs 8795$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2018 and its price was 8295$. If we compare this with the average Crosscountry bike cost we notice that the price is 335.43% higher.
Overview of components
Fork
The Fox Factory Float 32 is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Ellsworth Truth Convert Shimano XTR 27.5″+ bike has the FOX Float DPS Factory model installed, and has a travel of 100mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Ellsworth Truth Convert Shimano XTR 27.5″+ 2018, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Truth Convert Shimano XTR 27.5″+ has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Ellsworth Truth Convert Shimano XTR 27.5″+ bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Ellsworth Truth Convert Shimano XTR 27.5″+ comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
