Evil Insurgent LS SRAM X01 AXS Eagle I9 Hydra MX 2023
2023 Mountain
Estimate price |
10,469$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 168mm -
Fork RockShox ZEB Ultimate
-
Groupset X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Insurgent 168mm of travel, UD Carbon, Full Internal Cable Routing, SB+ 157mm Rear Spacing Integrated Chain Guide, Threaded BB, UDH Compatible
Suspension Fork
Rockshox Zeb Ultimate, Charger 3 RC2 W/ ButterCups, 29”, 170mm Travel, 44mm Offset
Rear Shock
Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, LN L1 HB 38TS, S/M: 350lbs, L/XL 400lbs
Drivetrain
Rear Derailleur
SRAM X01 AXS Eagle Transmission Derailleur
Shift Levers
SRAM AXS Controller
Cassette
SRAM X01 Eagle XG1295 10-52T
Crank
SRAM X01 Eagle Lunar Polar DUB carbon, 32t ring, 170mm
Bottom Bracket
SRAM DUB 73mm BSA, 7.5mm Spacer Drive/3mm Spacer Non-Drive
Chain
SRAM GX Eagle w/Powerlock
Wheels
Rims
Industry Nine Enduro S Hydra 29 Internal Width: 30.5mm, Hub: 110x15mm
Tires
Maxxis Minion DHF EXO TR, 29x2.5
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Evil 12 Gauge, Clamp: 35mm, Length: 45mm
Handlebar
Evil Boomstick Carbon, Backsweep: 8°, Upsweep 5° Clamp:35mm, Rise: 35mm, Width: 810mm
Grips
Evil Palmela Handerson lock-on
Headset
Works Components 1 Degree Angleset
Seat
Saddle
WTB Volt Pro
Seatpost
Bike Yoke Revive, S:125mm, M: 160mm, L:185m XL: 213mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM Low | SM Low | MD Low | MD Low | LG Low | LG Low | XL Low | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.374 mm | 1.342 mm | 1.343 mm | 1.313 mm | 1.311 mm | 1.285 mm | 1.281 mm | 1.256 mm |
| Bottom Bracket Height | 341 mm | 349 mm | 341 mm | 349 mm | 341 mm | 349 mm | 341 mm | 349 mm |
| Front Center | 781 mm | 781 mm | 803 mm | 803 mm | 828 mm | 828 mm | 853 mm | 853 mm |
| Rake | 44 mm | 43 mm | 44 mm | 44 mm | 44 mm | 45 mm | 44 mm | 45 mm |
| Trail | 120 mm | 116 mm | 120 mm | 116 mm | 120 mm | 116 mm | 120 mm | 116 mm |
| Stack | 617 mm | 612 mm | 626 mm | 621 mm | 637 mm | 632 mm | 648 mm | 643 mm |
| Reach | 449 mm | 456 mm | 466 mm | 473 mm | 486 mm | 492 mm | 506 mm | 512 mm |
| Top Tube Length | 593 mm | mm | 610 mm | mm | 631 mm | mm | 652 mm | mm |
| Seat Tube Angle | 77.5 ° | 78.2 ° | 77.5 ° | 78.2 ° | 77.5 ° | 78.2 ° | 77.5 ° | 78.2 ° |
| Head Tube Angle | 64.7 ° | 65.3 ° | 64.7 ° | 65.3 ° | 64.7 ° | 65.3 ° | 64.7 ° | 65.3 ° |
| Chainstay Length | 432 mm | 430 mm | 432 mm | 430 mm | 432 mm | 430 mm | 432 mm | 430 mm |
| Wheelbase | 1213 mm | 1211 mm | 1235 mm | 1233 mm | 1260 mm | 1258 mm | 1285 mm | 1283 mm |
| Bottom Bracket Drop | 16 mm | 8 mm | 16 mm | 8 mm | 16 mm | 8 mm | 16 mm | 8 mm |
| Standover Height | 686 mm | 692 mm | 696 mm | 703 mm | 704 mm | 711 mm | 718 mm | 724 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
Model Overview
Insurgent LS SRAM X01 AXS Eagle I9 Hydra MX completes the Evil Insurgent model. There are 48 bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Evil Insurgent – LS SRAM GX MECHANICAL i9 HYDRA MX 2023 is the cheapest bike model and costs 6999$. Evil Insurgent LS SRAM X01 AXS Eagle I9 Hydra 2023 is the most expensive one and costs 9555$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Evil Insurgent LS SRAM X01 AXS Eagle I9 Hydra MX price was 9555$. In conclusion, this bike price is 165.49% more expensive than the price of the average Enduro bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Insurgent LS SRAM X01 AXS Eagle I9 Hydra MX components
Fork
The fork installed on this bike is the RockShox ZEB Ultimate model. The travel on this model is 170mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the Rockshox Super Deluxe Coil Ultimate rear shock model, which has a travel of 168mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Evil Insurgent LS SRAM X01 AXS Eagle I9 Hydra MX 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
