Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 29" -
Travel Front 150mm -
Travel Rear 135mm -
Fork Fox Factory Float 36
-
Groupset X01 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari Delano Peak CleanCast Carbon TetraLink Full Suspension, 135mm travel. Internal Future-Proof cable routing on top of downtube. CleanCatch rattle-proof cable guides. SRAM Universal Derailleur Hanger. 2 Flush-mount bottle cages (S,M,L,XL)
Suspension Fork
Fox 36,Factory, 150mm travel, Grip 2 Damper, 44mm offset
Rear Shock
Fox Float DPX2, Factory, 3 position, 210x50, 25x8mm/30x8mm bearing mount
Drivetrain
Rear Derailleur
SRAM X01 Eagle 12-spd
Front Derailleur
N/A
Shift Levers
SRAM Eagle X01 Eagle trigger shifter
Cassette
SRAM XG 1295 10-52T
Crank
SRAM X01 Eagle Carbon DUB
Bottom Bracket
SRAM DUB English thread, 73mm
Chain
SRAM X01 Eagle, 12-spd
Pedals
Available Separately
Wheels
Front Hub
Industry9 1/1, 110x15/148x12, XD driver, Centerlock
Rear Hub
Industry9 1/1, 110x15/148x12, XD driver, Centerlock
Rims
Crank Brothers Synthesis 11, Carbon
Spokes
Sapim D-light
Tires
Front: Maxxis Minion DHF 29x2.5" 60 TPI, EXO, Tubeless Ready, Rear: Maxxis Aggressor 29x2.5" 60 TPI, EXO, Tubeless Ready
Brakes
Brakes
SRAM Code RSC, Centerline 180/180mm rotors
Brake Levers
SRAM Code RSC
Cockpit
Stem
ProTape 31.8 Alloy Stem
Handlebar
ProTaper, 31.8mm, 810mm, 25mm riser Carbon, customized sizing through 23-Point Custom Setup
Headset
Cane Creek 40, ZS44/28.6 ZS56/40
Seat
Saddle
Selle Italia X Superflow
Seatpost
PNW Bachelor Internal Dropper with Loam Lever Remote (Travel adjusted with 23-point customs fit after checkout
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.419 mm | 1.341 mm | 1.308 mm | 1.284 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 744 mm | 777 mm | 801 mm | 827 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 133 mm | 124 mm | 134 mm | 134 mm |
| Stack | 610 mm | 610 mm | 628 mm | 642 mm |
| Reach | 430 mm | 455 mm | 480 mm | 500 mm |
| Top Tube Length | 560 mm | 593 mm | 613 mm | 637 mm |
| Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| Seat Tube Length | 400 mm | 420 mm | 445 mm | 460 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 95 mm | 95 mm | 115 mm | 130 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1176 mm | 1209 mm | 1234 mm | 1260 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm | 28 mm |
| Standover Height | 734 mm | 741 mm | 751 mm | 763 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Delano Peak Pro completes the Fezzari Delano model. Fezzari launched 40 bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Fezzari Delano Peak Comp Eagle 2022 is the cheapest bike model and costs 3799$. Fezzari Delano Peak Pro 2022 is the most expensive one and costs 6899$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Fezzari released this model in 2022, its price was 6899$. In conclusion, this bike price is 149.78% higher than the price of the average Trail bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Delano Peak Pro components
Fork
Fezzari Delano Peak Pro 2022 bike is equipped with the Fox Factory Float 36 fork, and has 150mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The Delano Peak Pro has a rear shock with a travel of 135mm. The model Fox Float DPX2 is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
As for the wheels, Fezzari Delano Peak Pro 2022, has a 29″ carbon model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the Delano Peak Pro. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
