Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari DFA1 compact design, double-butted, heat-treated, light-weight aluminum, *Note: Smaller frames do not support second set of bottle cage bosses
Suspension Fork
Fezzari FD2 Carbon Fork
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Sora R3000 GS, 9 speed
Front Derailleur
Shimano Sora R3000, 34.9 clamp, 2 speed, new longer actuation arm for smoother easier shifting
Shift Levers
Shimano Sora R3000, 2x9 speed Rapid-Fire Plus with optical gear display
Cassette
Sunrace CSM90, 9 speed, 11x34t, extra wide range for easier hill climbing without sacrificing high gear
Crank
FSA Vero Pro Adventure, anodized black
Bottom Bracket
FSA BB7420, JIS, heavy duty
Chain
KMC X9 NP/GY, 9 speed
Pedals
N/A
Wheels
Front Hub
Alex, 32 hole, Front 12x100 thru axle, Rear 10x135 QR
Rear Hub
Alex, 32 hole, Front 12x100 thru axle, Rear 10x135 QR
Rims
WTB ST i21 TCS 2.0, 32 hole, Disc only, Tubeless ready
Spokes
2.0mm (14g) stainless
Tires
Maxxis Re-Fuse, 700x40c Tubeless ready, Kevlar puncture protection
Brakes
Brakes
Shimano BR-UR300 Hydraulic Disc Brake
Brake Levers
Shimano BL-MT200, reach adjust
Cockpit
Stem
Fezzari 3D forged alloy, 31.8mm 4-bolt bar clamp (rise and length customizable through 23-Point Custom Setup)
Handlebar
Fezzari alloy, double butted 31.8mm, blast black (width customizable through 23-Point Custom Setup)
Headset
FSA Orbit 1.5 ZS NO.57E
Seat
Saddle
Selle Italia Model X
Seatpost
Fezzari Racing Design XrT Dual Bolt Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.5 mm | 1.52 mm | 1.49 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 619 mm | 645 mm | 667 mm | 687 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 70 mm | 70 mm | 68 mm | 70 mm |
| Stack | 589 mm | 608 mm | 632 mm | 646 mm |
| Reach | 385 mm | 405 mm | 417 mm | 434 mm |
| Top Tube Length | 549 mm | 579 mm | 599 mm | 619 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 165 mm | 185 mm | 210 mm | 225 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1044 mm | 1070 mm | 1092 mm | 1112 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 767 mm | 789 mm | 794 mm | 801 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Murdock is part of the Fezzari Murdock model. Fezzari released 8 bikes variations of this model so far. Take a sneak peek at all Fezzari Murdock bikes models from 2021, by clicking here.
Model range prices
The most economical model, the Fezzari Murdock 2021 has a starting price of 999$. Fezzari Murdock Apex 1x 2021 on the other hand is the most expensive at 1199$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Commuter bikes average price
According to our math, the average price for a trustworthy Commuter bike is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2021 for 999$. Comparing the average cost of a Commuter bike to this one, you will see that Murdock price is 31.1% higher.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on Murdock are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Murdock comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Fezzari Murdock bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
