Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Apex 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari DFA1 compact design, double-butted, heat-treated, light-weight aluminum, *Note: Smaller frames do not support second set of bottle cage bosses
Suspension Fork
Fezzari FD2 Carbon Fork
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Apex 1, Wide Range
Front Derailleur
N/
Shift Levers
SRAM Apex 1x11 Flat Bar Shifter, Wide Range
Cassette
SRAM PG-1130 11-42t, Wide Range
Crank
SRAM Apex 1x
Bottom Bracket
SRAM GXP English, 68mm
Chain
SRAM PC-1110
Pedals
N/A
Wheels
Front Hub
Bear Pawls, 32 hole, Front 12x100 thru axle, Rear 10x135 QR
Rear Hub
Bear Pawls, 32 hole, Front 12x100 thru axle, Rear 10x135 QR
Rims
WTB ST i21 TCS 2.0, 32 hole, Disc only, Tubeless ready
Spokes
2.0mm (14g) stainless
Tires
Maxxis Refuse 700x40c Tubeless Ready, Kevlar lined puncture protection
Brakes
Brakes
SRAM Level, SRAM Centerline 160mm/160mm F/R Rotors
Brake Levers
SRAM Level
Cockpit
Stem
Fezzari 3D forged alloy, 31.8mm 4-bolt bar clamp (rise and length customizable through 23-Point Custom Setup)
Handlebar
Fezzari alloy, double butted 31.8mm, blast black (width customizable through 23-Point Custom Setup)
Headset
FSA Orbit 1.5 ZS NO.57E
Seat
Saddle
Selle Italia Model X Super Flow
Seatpost
Fezzari Racing Design XrT Dual Bolt Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.5 mm | 1.52 mm | 1.49 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 619 mm | 645 mm | 667 mm | 687 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 70 mm | 70 mm | 68 mm | 70 mm |
| Stack | 589 mm | 608 mm | 632 mm | 646 mm |
| Reach | 385 mm | 405 mm | 417 mm | 434 mm |
| Top Tube Length | 549 mm | 579 mm | 599 mm | 619 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm | 600 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 165 mm | 185 mm | 210 mm | 225 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1044 mm | 1070 mm | 1092 mm | 1112 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 767 mm | 789 mm | 794 mm | 801 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Murdock Apex 1x belongs to the Fezzari Murdock model. 8 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
The most economical model, the Fezzari Murdock 2021 has a starting price of 999$. Fezzari Murdock Apex 1x 2021 on the other hand is the most expensive at 1199$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Commuter bikes
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Fezzari released this model in 2021, its price was 1199$. Comparing this to the average Commuter bike price, we see that the price is 57.35% higher.
Overview of components
Fork material
Murdock Apex 1x has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Fezzari Murdock Apex 1x 2021, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Murdock Apex 1x comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
