Fezzari Signal Peak SL Pro AXS 2023
2023 Mountain
Estimate price |
6,699$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox SID SL Ultimate
-
Groupset GX Eagle AXS, Truvativ Descendant Carbon -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari Signal Peak SL CleanCast™ Carbon TetraLink™ Full Suspension, 100mm travel. Internal FutureProof™ cable routing on top of Downtube. CleanCatch™ rattle-proof cable guides. UDH derailleur hanger. ISCG-05 mounts, two hole. 2 flush-mount bottle cages (all frame sizes)
Suspension Fork
Rockshox SID SL Ultimate Race Day Charger Remote 100mm travel, 15x110 Axle, tapered steerer
Rear Shock
Rockshox SIDLuxe Ultimate Remote Lockout 100mm
Drivetrain
Rear Derailleur
SRAM GX AXS Eagle 12-Speed
Front Derailleur
N/A
Shift Levers
SRAM GX AXS Eagle Trigger 12-Speed
Cassette
SRAM XG-1275 GX Eagle, 10-52t, 12-speed
Crank
SRAM Descendant Eagle Carbon Eagle DUB-customized sizing through 23-Point Custom Setup
Bottom Bracket
SRAM DUB BSA MTB73
Chain
SRAM GX Eagle 12-speed
Pedals
Available Separately
Wheels
Front Hub
Front: Industry Nine 1/1, Disc, 15x110 thru axle, Rear: Industry Nine 1/1, Disc, 12x148 thru axle, XD
Rear Hub
Front: Industry Nine 1/1, Disc, 15x110 thru axle, Rear: Industry Nine 1/1, Disc, 12x148 thru axle, XD
Rims
Enve AM30 Carbon. Additional options at checkout
Spokes
Sapim D-light
Tires
Maxxis Ikon 29x2.35, EXO, TR Protection, Tubeless Ready
Brakes
Brakes
SRAM Level TLM, 180/160mm F/R Rotors
Cockpit
Stem
Fezzari CNC35 stem
Handlebar
Fezzari team 35mm bar. Customized sizing through 23-Point Custom Setup
Headset
Cane Creek 40 Series ZS Tapered ZS44 ZS56/40
Seat
Saddle
Selle Italia Model X
Seatpost
Fezzari Carbon Race Seatpost 31.6, Dropper post available at checkout
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.36 mm | 1.33 mm | 1.3 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 720 mm | 737 mm | 759 mm | 780 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 114 mm | 116 mm | 116 mm | 116 mm |
| Stack | 611 mm | 617 mm | 626 mm | 635 mm |
| Reach | 437 mm | 453 mm | 471 mm | 488 mm |
| Top Tube Length | 598 mm | 615 mm | 634 mm | 653 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 425 mm | 455 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 120 mm | 125 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1153 mm | 1170 mm | 1192 mm | 1213 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 735 mm | 740 mm | 750 mm | 762 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Signal Peak SL Pro AXS is part of the Fezzari Signal model. Fezzari launched 60 bikes of this model so far. Take a sneak peek at all Fezzari Signal bikes models from 2023, by clicking here.
Model range prices
Fezzari Signal Peak TR Comp 2023 is the most affordable bike of this model and has a price of 3799$. On the other hand, Fezzari Signal Peak TR Team XX SL Transmission 2023, is the most expensive and costs 9499$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Fezzari released this model in 2023, its price was 6699$. Doing a quick comparison, we notice that Signal Peak SL Pro AXS price is 251.65% higher than the average cost of a Crosscountry bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Signal Peak SL Pro AXS components
Fork
The RockShox SID SL Ultimate is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Fezzari Signal Peak SL Pro AXS bike has the Rockshox SIDLuxe Ultimate Remote Lockout 100mm model installed, and has a travel of 100mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The Signal Peak SL Pro AXS 2023 bike is equipped with 29″ carbon wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Signal Peak SL Pro AXS has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
