Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 115mm -
Fork RockShox SID Ultimate
-
Groupset X0 Eagle Transmission, X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari Signal Peak SL CleanCast™ Carbon TetraLink™ Full Suspension, 115mm travel. Internal FutureProof™ cable routing on top of Downtube. CleanCatch™ rattle-proof cable guides. UDH derailleur hanger. ISCG-05 mounts, two hole. 2 flush-mount bottle cages (all frame sizes)
Suspension Fork
Rockshox SID Ultimate Race Day Charger 3 Postion Crown Adjust, 120mm travel, 15x110 Axle, tapered steerer
Rear Shock
Rockshox SIDLuxe Ultimate 3 Position Lever Lockout 115mm
Drivetrain
Rear Derailleur
SRAM XO Eagle Transmission 12-Speed
Front Derailleur
N/A
Shift Levers
SRAM AXS POD 12-Speed
Cassette
SRAM XS-1295 XO Eagle Transmission, 10-52t, 12-speed
Crank
SRAM XO Eagle Daul Guard, DUB Wide-customized sizing through 23-Point Custom Setup
Bottom Bracket
SRAM DUB BSA MTB73
Chain
SRAM XO Eagle Transmission Flattop 12-speed
Pedals
Available Separately
Wheels
Front Hub
Front: DT Swiss 240 Hub, Disc, 15x110 thru axle, Rear: DT Swiss 240 Ratchet aluminum hub, Disc, 12x148 thru axle, XD
Rear Hub
Front: DT Swiss 240 Hub, Disc, 15x110 thru axle, Rear: DT Swiss 240 Ratchet aluminum hub, Disc, 12x148 thru axle, XD
Rims
DT Swiss XRC 1501, Carbon 29
Tires
Maxxis Rekon Race 29x2.35, EXO, TR Protection, Tubeless Ready
Brakes
Brakes
SRAM Level Silver Stealth 4-Piston, 180/180mm F/R Rotors
Cockpit
Stem
Fezzari CNC35 stem
Handlebar
Fezzari team 35mm bar. Customized sizing through 23-Point Custom Setup
Headset
Cane Creek 40 Series ZS Tapered ZS44 ZS56/40
Seat
Saddle
Selle Italia X3
Seatpost
PNW Rainier customized sizing through 23-Point Custom Setup
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.36 mm | 1.33 mm | 1.3 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 720 mm | 737 mm | 759 mm | 780 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 114 mm | 116 mm | 116 mm | 116 mm |
| Stack | 611 mm | 617 mm | 626 mm | 635 mm |
| Reach | 437 mm | 453 mm | 471 mm | 488 mm |
| Top Tube Length | 598 mm | 615 mm | 634 mm | 653 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 425 mm | 455 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 120 mm | 125 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1153 mm | 1170 mm | 1192 mm | 1213 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 735 mm | 740 mm | 750 mm | 762 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Signal Peak SL Pro TR Transmission belongs to the Fezzari Signal model. 60 bikes variations carry this model name so far. Take a sneak peek at all Fezzari Signal bikes models from 2023, by clicking here.
Model range prices
Fezzari Signal Peak TR Comp 2023 is the most affordable bike of this model and has a price of 3799$. On the other hand, Fezzari Signal Peak TR Team XX SL Transmission 2023, is the most expensive and costs 9499$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Signal Peak SL Pro TR Transmission components
Fork
This bike has the RockShox SID Ultimate fork installed. The fork’s travel is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the Rockshox SIDLuxe Ultimate 3 Position Lever Lockout 115mm rear shock model, which has a travel of 115mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on Signal Peak SL Pro TR Transmission are the 29″ carbon type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Fezzari Signal Peak SL Pro TR Transmission has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Fezzari Signal Peak SL Pro TR Transmission bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
