Fezzari Signal Peak TR Comp Shimano 2023
2023 Mountain
Estimate price |
3,799$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 115mm -
Fork DVO Sapphire 32
-
Groupset SLX, Shimano -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fezzari Signal Peak CleanCast™ Carbon TetraLink™ Full Suspension, 115mm travel. Internal FutureProof™ cable routing on top of Downtube. CleanCatch™ rattle-proof cable guides. UDH derailleur hanger. ISCG-05 mounts, two hole. 2 flush-mount bottle cages (all frame sizes)
Suspension Fork
DVO Sapphire D1 120mm Travel, 110x15mm thru axle, tapered steerer
Rear Shock
DVO Opal T2 115mm, Custom Tuned
Drivetrain
Rear Derailleur
Shimano SLX 12-Speed
Front Derailleur
N/A
Shift Levers
Shimano SLX Trigger 12-Speed
Cassette
Shimano SLX, 10-51T, 12-speed
Crank
Shimano FC-MT510-1
Bottom Bracket
Shimano BB-MT501 English Thread
Chain
Shimano SLX 12-speed
Pedals
Available Separately
Wheels
Front Hub
F: Bear Pawls Sealed Bearing Disc, 110x15mm thru axle, 32 hole, 6 bolt; R: Bear Pawls Sealed Bearing Disc, 148x12mm thru axle, 32 hole, 6 bolt
Rear Hub
F: Bear Pawls Sealed Bearing Disc, 110x15mm thru axle, 32 hole, 6 bolt; R: Bear Pawls Sealed Bearing Disc, 148x12mm thru axle, 32 hole, 6 bolt
Rims
Stans Flow D 29 disc specific, tubeless ready
Spokes
15G Stainless, black, with brass nipple
Tires
Maxxis Minion DHF 29x2.5, EXO, TR Protection, Tubeless Ready, Aggressor 29x2.5, EXO, TR Protection, Tubeless Ready
Brakes
Brakes
SRAM DB8, 180mm/160 F/R rotors
Cockpit
Stem
Fezzari CNC35 stem
Handlebar
Fezzari team 35mm bar. Customized sizing through 23-Point Custom Setup
Headset
Cane Creek 40 Series ZS Tapered ZS44 ZS56/40
Seat
Saddle
Ergon SM10
Seatpost
PNW Rainier Dropper- customized sizing through 23-Point Custom Setup
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.36 mm | 1.33 mm | 1.3 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm | 341 mm |
| Front Center | 720 mm | 737 mm | 759 mm | 780 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 114 mm | 116 mm | 116 mm | 116 mm |
| Stack | 611 mm | 617 mm | 626 mm | 635 mm |
| Reach | 437 mm | 453 mm | 471 mm | 488 mm |
| Top Tube Length | 598 mm | 615 mm | 634 mm | 653 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 405 mm | 425 mm | 455 mm | 480 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 100 mm | 105 mm | 120 mm | 125 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1153 mm | 1170 mm | 1192 mm | 1213 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 735 mm | 740 mm | 750 mm | 762 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Signal Peak TR Comp Shimano completes the Fezzari Signal model. Fezzari released 60 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Fezzari Signal Peak TR Comp 2023 is the most affordable bike of this model and has a price of 3799$. On the other hand, Fezzari Signal Peak TR Team XX SL Transmission 2023, is the most expensive and costs 9499$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Fezzari Signal Peak TR Comp Shimano price was 3799$. Doing a quick comparison, we notice that Signal Peak TR Comp Shimano price is 99.42% higher than the average cost of a Crosscountry bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
Fezzari Signal Peak TR Comp Shimano 2023 bike is equipped with the DVO Sapphire 32 fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Signal Peak TR Comp Shimano has a rear shock with a travel of 115mm. The model DVO Opal T2 115mm is the one installed in this bike. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When it comes to wheels, the Signal Peak TR Comp Shimano bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Fezzari Signal Peak TR Comp Shimano has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Signal Peak TR Comp Shimano comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the Signal Peak TR Comp Shimano. Therefore, climbing or descending will be a breeze.
