flyer Goroc TR:X 8.63 High 2023
2023 E-bike
Estimate price |
10,469$
Weight | 30 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Fox AWL
-
Suspension Full -
Motor 600W 85Nm mid-drive -
Battery TP 700 48V FIT (700 Wh / 15 Ah / 48 V); compatible with Range Extender -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 166cm
MD
164cm - 176cm
LG
174cm - 186cm
XL
184cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FLYER Engineered, Carbon/Aluminium, 4-link suspension, 130 mm travel
Suspension Fork
Fox AWL, 130 mm travel, 15 × 110 mm boost
Rear Shock
Fox Float DPS, 210 x 50 mm
Drivetrain
Cassette
Pinion Motor Gearbox Unit (MGU), E1.12 with Comfort Set-Up, 12 speed; Gates Carbon Drive CDX
Pedals
VP 527
Wheels
Front Hub
MAVIC eCrossride 1
Rear Hub
MAVIC eCrossride 1
Rims
MAVIC eCrossride 1, 30 mm
Tires
Schwalbe Johnny Watts E-50 29 x 2.35 (60-622)
Brakes
Brakes
TRP C2.3, 203/203 mm
Cockpit
Stem
FLYER ONE CI Stem, 35 x 40 mm, 8°
Handlebar
FLYER Alloy, 740 mm, 7°, 25 mm
Seat
Saddle
Selle Royal Essenza+
Seatpost
FLYER Dropper Post MT171, 100 (S) / 125 (M) / 150 (L-XL) mm Travel, 34.9 mm
Motor & Battery
Motor
Pinion MGU E1.12, 600 W (85 Nm)
Battery
TP 700 48V FIT (700 Wh / 15 Ah / 48 V); compatible with Range Extender
Charger
FIT Fast Charger 5A 48V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.46 mm | 1.41 mm | 1.37 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 762 mm | 781 mm | 805 mm | 829 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 126 mm | 122 mm | 122 mm | 122 mm |
| Stack | 636 mm | 648 mm | 657 mm | 666 mm |
| Reach | 425 mm | 445 mm | 465 mm | 485 mm |
| Top Tube Length | 593 mm | 618 mm | 642 mm | 667 mm |
| Seat Tube Angle | 75.3 ° | 75.1 ° | 75 ° | 74.9 ° |
| Seat Tube Length | 412 mm | 441 mm | 471 mm | 511 mm |
| Head Tube Angle | 65 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 140 mm | 150 mm | 160 mm | 170 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1225 mm | 1244 mm | 1268 mm | 1292 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 195 cm |
About this model
Goroc TR:X 8.63 High completes the Flyer E Goroc model. There are 7 e-bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Flyer Goroc X 2.10 High 2023 is the most affordable e-bike of this model and has a price of 6051$. On the other hand, Flyer Goroc TR:X 8.63 HS High 2023, is the most expensive and costs 11254$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail e-bikes
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, even though the average price of a Trail e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Flyer Goroc TR:X 8.63 High price was 9555$. Comparing this to the average Trail e-bike price, we see that the price is 183.95% higher.
Average weight for Trail e-bikes
Trail e-bikes have an average weight of 23.02 kg (50.75 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 30 kg (66.14 lbs), Flyer e-bike is much heavier than average. In other words, this model is 30.32% heavier than the average Trail e-bike.
Goroc TR:X 8.63 High components
Fork
This e-bike has the Fox AWL fork installed. The fork’s travel is 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the Fox Float DPS rear shock model, which has a travel of 130mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the Goroc TR:X 8.63 High e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Flyer Goroc TR:X 8.63 High is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Flyer Goroc TR:X 8.63 High e-bike has 4 sizes, in the range of 155 cm – 195 cm (5.09 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
The Flyer model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
