Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Deore, FSA -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy front triangle, Fuji A1-SL alloy rear triangle
Suspension Fork
SR Suntour SF20-XCM-RL-DS-29, remote lockout, 100mm
Drivetrain
Rear Derailleur
Shimano Deore
Shift Levers
Shimano Deore, 1 x 11-speed
Cassette
Sunrace, 11-50T
Crank
FSA Gamma Pro, 30T
Bottom Bracket
FSA Mega Exo, threaded
Chain
KMC X11
Pedals
Resin platform
Wheels
Rims
WTB SX19 rims 32H, Shimano HB-TX505 front, FH-TX505 rear hub, stainless black spokes
Tires
WTB Ranger Comp, 29" x 2.25", 27tpi
Brakes
Brakes
Shimano MT200, 180/160mm rotors
Brake Levers
Shimano MT201
Cockpit
Stem
Fuji, forged aluminum, +/-6°
Handlebar
Fuji flat bar, alloy, 710mm
Grips
Fuji Performance Grip Lock On
Headset
1 1/8" sealed bearings
Seat
Saddle
WTB Volt Sport
Seatpost
Fuji, alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.47 mm | 1.4 mm | 1.38 mm | 1.35 mm |
| Front Center | 669 mm | 690 mm | 715 mm | 733 mm | 752 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Stack | 615.5 mm | 625 mm | 629.5 mm | 639 mm | 648 mm |
| Reach | 408 mm | 425 mm | 449 mm | 463 mm | 479 mm |
| Top Tube Length | 595 mm | 615 mm | 640 mm | 657 mm | 676 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 370 mm | 420 mm | 470 mm | 520 mm | 560 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 105 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1117 mm | 1138 mm | 1164 mm | 1181 mm | 1201 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 785 mm | 813 mm | 838 mm | 866 mm | 890 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
Nevada 29 1.3 completes the Fuji Nevada model. There are 246 bikes that carry this model name. You can easily view all of the Fuji Nevada bikes models from 2023, here.
Model range prices
The most economical model, the Fuji Nevada 27.5 1.9 2023 has a starting price of 417$. Fuji Nevada 29 1.0 LTD 2023 on the other hand is the most expensive at 1164$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Mountain bikes average price
According to our calculations, the average cost of a Mountain bike that is reliable is 616$. However, even though the average price of a Mountain bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Fuji Nevada 29 1.3 price was 949$. Comparing the average cost of a Mountain bike to this one, you will see that Nevada 29 1.3 price is 54.06% more expensive.
Nevada 29 1.3 components
Fork
Fuji Nevada 29 1.3 2023 bike is equipped with the Suntour XCM fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The Nevada 29 1.3 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Nevada 29 1.3 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
