Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Sektor
-
Groupset NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 175cm
MD
173cm - 180cm
LG
178cm - 185cm
XL
173cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy, sealed cartridge bearing pivots, A4 suspension, Boost 148x12mm, 120mm
Suspension Fork
RockShox Sektor RL 29 Solo Air, tapered alloy steerer, Boost 110x15mm, 130mm
Rear Shock
RockShox Deluxe RL
Drivetrain
Rear Derailleur
SRAM NX Eagle
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, 1 x 12-speed
Cassette
SRAM PG-1230 10-50T
Crank
SRAM NX Eagle, 32T
Bottom Bracket
SRAM DUB, threaded
Chain
SRAM NX Eagle
Pedals
Alloy platform
Wheels
Rims
WTB ST i25 TCS 32H rims, Formula DC-711 front, DC-1248 rear, stainless black spokes
Tires
Maxxis Ardent, 29" x 2.40", 60tpi, EXO, Tubeless Ready, folding
Brakes
Brakes
SRAM Guide T, 180mm rotors
Brake Levers
SRAM Guide T
Cockpit
Stem
Oval Concepts 313, 3D-forged alloy, ±7°
Handlebar
Oval Concepts 205 riser bar, 6061 alloy, ± 5mm rise, 760mm
Grips
WTB Waffel Grip, Single lock on
Headset
FSA 1 1/8" - 1.5", sealed bearings
Seat
Saddle
WTB Volt Sport
Seatpost
KS E30i Integra dropper, 30.9mm, 15, 17" - 100mm travel, 19, 21" - 125mm travel, Southpaw Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.36 mm | 1.31 mm | 1.28 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 697 mm | 723 mm | 749 mm | 770 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 96 mm | 96 mm | 96 mm | 96 mm |
| Stack | 588.9 mm | 598.1 mm | 607.4 mm | 616.7 mm |
| Reach | 418 mm | 440.4 mm | 462.8 mm | 480.3 mm |
| Top Tube Length | 581 mm | 606 mm | 631 mm | 651 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 401 mm | 432 mm | 486.2 mm | 536.3 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1134 mm | 1160 mm | 1186 mm | 1207 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 797 mm | 802 mm | 815 mm | 838 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 173 cm | 178 cm | 173 cm |
| Rider Max Height | 175 cm | 180 cm | 185 cm | 193 cm |
About this model
Outland 29 1.0 belongs to the Fuji Outland model. Fuji released 69 bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Fuji Outland 29 1.3 2020 is the most affordable bike of this model and has a price of 1299$. On the other hand, Fuji Outland 29 1.0 2020, is the most expensive and costs 2299$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2020 and its price was 2299$. Comparing this to the average Trail bike price, we see that the price is 20.14% lower.
Overview of components
Fork
This bike has the RockShox Sektor fork installed. The fork’s travel is 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
The shock that’s installed on this bike is RockShox Deluxe RL, with a travel distance of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The Outland 29 1.0 2020 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Outland 29 1.0 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 165 cm – 193 cm (5.41 ft – 6.33 ft). In short, you can easily find one that suits you.
Dropper post
Fuji Outland 29 1.0 includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
