Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Judy Silver TK
-
Groupset Deore, FSA -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy front and rear triangle w/ shaped oversized down tube, tapered 1 1/8" - 1.5" head tube, threaded bottom bracket, sealed cartridge bearing pivots, A4 suspension system, Boost 148x12mm dropout, replaceable hanger, 120mm travel
Suspension Fork
RockShox Judy Silver TK 29 Solo Air, tapered alloy steerer, Boost 110x15mm thru axle, 120mm travel
Rear Shock
RockShox Deluxe RL
Drivetrain
Rear Derailleur
Shimano Deore shadow plus, 10-speed
Front Derailleur
N/A
Shift Levers
Shimano Deore, Rapid Fire, 10-speed
Cassette
Shimano HG-500, 11-42T, 10-speed
Crank
FSA Gamma Pro, 30T
Bottom Bracket
FSA Mega EXO, threaded
Chain
KMC X10 w/ MissingLink, 10-speed
Pedals
Alloy platform
Wheels
Rims
WTB STP i25 rims 32H rims, Formula CL-511 Boost front, Formula DC-1248 Boost rear disc hubs, stainless black spokes, Tubeless Ready
Tires
Schwalbe Rocket Ron Performance, 29" x 2.25" 67tpi, Addix, folding, tubeless compatible
Brakes
Brakes
Shimano M315, hydraulic disc, 180/160mm rotors
Brake Levers
Shimano M315, hydraulic disc
Cockpit
Stem
Oval Concepts 313, 3D-forged 6061 stem body, ±7°
Handlebar
Oval Concepts 205 riser bar, 6061 alloy, ± 5mm rise, 9° sweep, 31.8mm clamp
Grips
Oval Concepts 634, large diameter pads, single lock on, dual density
Headset
FSA NO.42B, 1 1/8" - 1.5", semi-cartridge bearings
Seat
Saddle
Oval Concepts 238, steel rail
Seatpost
Oval Concepts, 6061 alloy, 30.9mm diameter
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.36 mm | 1.31 mm | 1.28 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 697 mm | 723 mm | 749 mm | 770 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 96 mm | 96 mm | 96 mm | 96 mm |
| Stack | 588.9 mm | 598.1 mm | 607.4 mm | 616.7 mm |
| Reach | 418 mm | 440.4 mm | 462.8 mm | 480.3 mm |
| Top Tube Length | 581 mm | 606 mm | 631 mm | 651 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 401 mm | 432 mm | 486.2 mm | 536.3 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1134 mm | 1160 mm | 1186 mm | 1207 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 797 mm | 802 mm | 815 mm | 838 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Outland 29 1.1 is a Fuji Outland model. 69 bikes variations carry this model name so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Fuji Outland 29 1.3 2018 is the cheapest bike model and costs 1549$. Fuji Outland 29 1.1 2018 is the most expensive one and costs 1949$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Fuji Outland 29 1.1 price was 1949$. Comparing this to the average Trail bike price, we see that the price is 41.71% lower.
Overview of components
Fork
The Outland 29 1.1 comes factory-installed with the RockShox Judy Silver TK fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
The shock that’s installed on this bike is RockShox Deluxe RL, with a travel distance of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The Outland 29 1.1 2018 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Outland 29 1.1 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Outland 29 1.1 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
