Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Rhythm Float 34
-
Groupset GX Eagle, Truvativ Descendant -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX Rhythm 34 Float, GRIP, 2-position
Rear Shock
FOX Float EVOL, Performance, 3-position
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle, 12-speed
Cassette
SRAM XG-1275, 10-50 tooth, 12-speed
Crank
Truvativ Descendant, 175mm (170mm size S)
Bottom Bracket
PF30
Chain
SRAM GX Eagle
Chain Guide
none
Pedals
none
Wheels
Front Hub
Front: Oval Concepts 600AM, 110mm x 15mm, centerlock, Rear: Oval Concepts 600AM, 148mm x 12mm, centerlock
Rear Hub
Front: Oval Concepts 600AM, 110mm x 15mm, centerlock, Rear: Oval Concepts 600AM, 148mm x 12mm, centerlock
Rims
Oval Concepts 600AM Boost Plus, 28-hole
Tires
Schwalbe Nobby Nic, 27.5" x 2.8" Snake Skin, Trail Star, 67tpi, folding, tubeless ready
Brakes
Brakes
TRP Slate T4 with 180mm rotors front and rear
Brake Levers
TRP Slate T4
Cockpit
Stem
Oval Concepts 313 alloy
Handlebar
Oval Concepts 205 alloy riser, 760mm width
Grips
Oval Concepts lock-on
Headset
FSA NO.9M/12B, sealed cartridge bearings
Seat
Saddle
Oval Concepts 238 trail, steel rail
Seatpost
KS Lev Integra
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.45 mm | 1.41 mm | 1.33 mm |
| Stack | 609.5 mm | 609.5 mm | 618.2 mm | 619.5 mm |
| Reach | 384 mm | 419 mm | 438.4 mm | 467.4 mm |
| Top Tube Length | 553.5 mm | 588.5 mm | 610.5 mm | 639.5 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 381.5 mm | 432.2 mm | 482.9 mm | 533.6 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 115 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1109 mm | 1144 mm | 1167 mm | 1196 mm |
| Standover Height | 764 mm | 774 mm | 774 mm | 791 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Rakan Plus 3.4 is a Fuji Rakan model. 37 bikes variations carry this model name so far. Take a sneak peek at all Fuji Rakan bikes models from 2018, by clicking here.
Model range prices
Fuji Rakan 29 3.6 2018 is the most economical model, with a starting price of 2499$. Fuji Rakan 29 3.4 2018 on the other hand costs 3699$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The Rakan Plus 3.4 comes factory-installed with the Fox Rhythm Float 34 fork. This has a travel range of 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Rakan Plus 3.4 has a rear shock with a travel of 120mm. The model FOX Float EVOL is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The Rakan Plus 3.4 2018 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Rakan Plus 3.4 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Fuji Rakan Plus 3.4 includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
