Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 20" -
Travel Front 40mm -
Fork Zoom
-
Groupset microSHIFT -
Suspension Hardtail -
Drivetrain 1 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
HTS steel
Suspension Fork
Zoom 565 suspension, 40 mm travel
Drivetrain
Rear Derailleur
Microshift M26CS, 7-speed
Front Derailleur
N/A
Shift Levers
Microshift TS71-7, Trigger
Cassette
Freewheel 14-32T, 7-speed
Crank
Aluminum,3-pcs, 28T
Bottom Bracket
Tange Square taper, 68 x 118 mm
Chain
KMC Z7
Pedals
Platform
Wheels
Front Hub
KT,QR 9 x 100 mm
Rear Hub
KT, freewheel, QR 10 x 135 mm
Rims
Aluminum, 20'', 28h
Spokes
14g, stainless steel
Tires
20 x 2,1''
Brakes
Brakes
Aluminum V-brake
Brake Levers
Junior specific, aluminum/resin
Cockpit
Stem
Aluminum, AheadSet, 40 mm, 7°
Handlebar
Aluminum, 40 mm rise, Ø25.4 mm
Grips
Garneau Junior
Headset
EC34 /28.6 | EC34 /30.0, 1 1/8'' threadless
Seat
Saddle
Garneau Junior
Seatpost
Aluminum, 1-bolt, Ø25.4 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM |
|---|---|
| Stack Reach Ratio | 1.76 mm |
| Front Center | 457 mm |
| Rake | 40 mm |
| Trail | 60 mm |
| Stack | 427 mm |
| Reach | 243 mm |
| Top Tube Length | 388 mm |
| Seat Tube Angle | 71.5 ° |
| Seat Tube Length | 240 mm |
| Head Tube Angle | 68 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 343 mm |
| Wheelbase | 798 mm |
| Bottom Bracket Drop | 30 mm |
| Standover Height | 496 mm |
| Front Travel | 40 mm |
| Wheels | 20" |
About this model
Trust 20 belongs to the Garneau Trust model. Garneau launched 8 bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Garneau Trust 20 2023 is the most economical model, with a starting price of 379$. Garneau Trust 27 2023 on the other hand costs 708$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Mountain bikes
Our math shows that the average cost of a dependable Mountain bike is 616$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Mountain bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2023 for 379$. Comparing the average cost of a Mountain bike to this one, you will see that Trust 20 price is 62.53% smaller.
Overview of components
Fork
The Zoom is included from the factory. It has a travel distance of 40mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Garneau Trust 20 2023, has a 20″ aluminum model. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Trust 20 comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
