Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Zoom
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
S-6 LT aluminum
Suspension Fork
Zoom 565 suspension, 100 mm travel
Drivetrain
Rear Derailleur
Shimano Tourney TY300
Front Derailleur
Shimano Tourney TY500, 7-speed
Shift Levers
Shimano EF500, EZ-Fire Plus
Cassette
Freewheel 14-34T, 7-speed
Crank
PW, 42/34/24T
Bottom Bracket
Square taper, 68 x 120 mm
Chain
KMC Z7
Pedals
Platform
Wheels
Front Hub
KT disc 6 bolt, QR 9 x 100 mm
Rear Hub
KT disc, freewheel, QR 10 x 135 mm
Rims
Torngat D21-27.5’’, alloy, disc, 32h
Spokes
14g, stainless steel
Tires
CST Jack Rabbit, 27.5 x 2.1"
Brakes
Brakes
Jieke ZJ-5, mechanical disc brake
Brake Levers
Shimano EF500
Cockpit
Stem
Aluminum, AheadSet, 6°
Handlebar
Aluminum, 30 mm rise, Ø31.8 mm
Grips
Garneau
Headset
ZS44/28.6 | ZS44/30.0, 1 1/8''
Seat
Saddle
Garneau explore
Seatpost
Aluminum, 2-bolt, Ø27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.49 mm | 1.48 mm | 1.46 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm |
| Front Center | 643 mm | 664 mm | 686 mm | 706 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 98 mm | 98 mm | 98 mm | 98 mm |
| Stack | 586 mm | 595 mm | 613 mm | 632 mm |
| Reach | 384 mm | 400 mm | 414 mm | 434 mm |
| Top Tube Length | 551 mm | 576 mm | 596 mm | 621 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 350 mm | 400 mm | 450 mm | 500 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 100 mm | 120 mm | 140 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1074 mm | 1095 mm | 1117 mm | 1137 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 708 mm | 725 mm | 766 mm | 781 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Trust 27 completes the Garneau Trust model. 8 bikes variations carry this model name so far. You can easily view all of the Garneau Trust bikes models from 2023, here.
Model range prices
The most economical model, the Garneau Trust 20 2023 has a starting price of 379$. Garneau Trust 27 2023 on the other hand is the most expensive at 708$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Garneau released this model in 2023, its price was 708$. Comparing this to the average Crosscountry bike price, we see that the price is 169.07% lower.
Overview of components
Fork
The fork installed on this bike is the Zoom model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on Trust 27 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, it won’t take much to find one that’s right for you.
