Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Titanium -
Wheels 700c -
Groupset GRX 800 -
Suspension Rigid -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Titainium
Drivetrain
Rear Derailleur
Shimano GRX RD-RX810 Medium Cage
Front Derailleur
Shimano GRX FD-RX810
Shift Levers
Shimano GRX ST-R810 11 Speed
Cassette
Shimano CS-HG800-11 11-34T
Bottom Bracket
Shimano BB-RS500
Chain
KMX X11
Pedals
NW-91K With Cage
Wheels
Front Hub
Formula Front - CL-712 / Rear - RXC-142S
Rear Hub
Formula Front - CL-712 / Rear - RXC-142S
Rims
WTB ST Light i23 TCS 2.0
Spokes
Steel 14 g
Tires
Kenda Booster 700 x 40c Tubeless Ready
Brakes
Brakes
Shimano GRX BR-RX810 Hydraulic Disc
Brake Levers
Shimano GRX ST-R810 11 Speed
Cockpit
Stem
Genesis Alloy 31.8mm -6 deg 100 mm
Headset
PT-1860BC IS42 Upper / IS52 Lower
Seat
Saddle
Genesis
Seatpost
Genesis Alloy 27.2 x 350 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.52 mm | 1.54 mm | 1.55 mm | 1.56 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 555 mm | 574 mm | 595 mm | 614 mm | 635 mm |
| Reach | 367 mm | 377 mm | 387 mm | 397 mm | 407 mm |
| Top Tube Length | 526 mm | 546 mm | 563 mm | 584 mm | 607 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° |
| Head Tube Length | 115 mm | 135 mm | 155 mm | 175 mm | 195 mm |
| Wheelbase | 1009 mm | 1025 mm | 1037 mm | 1054 mm | 1065 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 763 mm | 786 mm | 810 mm | 828 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Croix De Fer Ti completes the Genesis Croix model. Genesis launched 58 bikes of this model so far. You can easily view all of the Genesis Croix bikes models from 2020, here.
Model range prices
Genesis Croix de Fer 10 Flat Bar 2020 is the cheapest bike model and costs 1215$. Genesis Croix De Fer Ti 2020 is the most expensive one and costs 4864$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Genesis released this model in 2020, its price was 4864$. If we compare this with the average Gravel bike cost we notice that the price is 97.56% higher.
Croix De Fer Ti components
Wheels
When it comes to wheels, the Croix De Fer Ti bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Genesis Croix De Fer Ti has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Croix De Fer Ti comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
