Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Deore -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Reynolds 725 Heat-Treated Chromoly
Suspension Fork
Cr-Mo Unicrown Disc
Drivetrain
Rear Derailleur
Shimano Deore RD-M610 / SGS cage
Front Derailleur
Shimano Deore FD-T610-3
Shift Levers
Shimano Deore SL-M610 / 3x10 speed
Cassette
Shimano CS-HG500-10 / 11-34T
Crank
Shimano Deore FC-M522 / 44-32-24T / 170mm
Bottom Bracket
Shimano BB-ES300 68-121mm
Chain
KMC x10
Pedals
NW-99K w/ Toeclip
Wheels
Front Hub
SP PD-8/Shimano FH-M525 36h / front / rear / 6-bolt
Rear Hub
SP PD-8/Shimano FH-M525 36h / front / rear / 6-bolt
Rims
Sun Ringle Rhyno Lite / 36h
Spokes
Stainless steel 14g
Tires
Schwalbe Marathon Mondial 700x35c
Brakes
Brakes
Promax DSK-717 disc brakes w/ 160mm rotors
Brake Levers
Shimano BL-R550
Cockpit
Stem
Genesis AS-027 / + - 7deg / 100mm
Handlebar
Genesis alloy / 10mm rise / 12deg backsweep / XS, 580mm / S-M, 600mm / L-XL, 620mm
Headset
Prestine PT-1606 1-1/8" semi cartridge
Seat
Saddle
Genesis Road Comfort
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.55 mm | 1.52 mm | 1.49 mm | 1.47 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 597 mm | 612 mm | 639 mm | 664 mm | 691 mm |
| Rake | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Trail | 61 mm | 61 mm | 61 mm | 61 mm | 61 mm |
| Stack | 565 mm | 579 mm | 598 mm | 617 mm | 636 mm |
| Reach | 364 mm | 374 mm | 394 mm | 414 mm | 434 mm |
| Top Tube Length | 532 mm | 546 mm | 577 mm | 603 mm | 635 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 530 mm | 570 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 125 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1040 mm | 1055 mm | 1082 mm | 1108 mm | 1135 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 757 mm | 777 mm | 798 mm | 806 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Tour De Fer 20 is a Genesis Tour model. There are 25 bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Genesis Tour De Fer 10 2018 is the cheapest bike model and costs 1458$. Genesis Tour De Fer 30 2018 is the most expensive one and costs 2188$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2018 for 1823$. Comparing this to the average Gravel bike price, we see that the price is 35.05% lower.
Overview of components
Fork material
Tour De Fer 20 has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
The Tour De Fer 20 2018 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Tour De Fer 20 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
