Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum
Suspension Fork
SR Suntour XCT, 100mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano Tourney
Shift Levers
Shimano EF40
Cassette
Shimano TZ31 14x34, 7-speed
Crank
SR XCE, 28/38/48
Bottom Bracket
SR Suntour, threaded
Chain
KMC Z51
Pedals
Platform
Wheels
Front Hub
Alloy, 32h
Rear Hub
Alloy, 32h
Rims
Giant Alloy, Double-wall
Spokes
Stainless Steel, 14g
Tires
Giant Sport, 27.5x2.1
Brakes
Brakes
Tektro, mechanical disc, 160mm
Brake Levers
Tektro
Cockpit
Stem
Giant Sport
Handlebar
Giant Sport, Low Rise, 31.8mm
Seat
Saddle
Giant Connect Upright
Seatpost
Giant Sport, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.514 mm | 1.517 mm | 1.499 mm | 1.447 mm | 1.417 mm | 1.373 mm |
| Stack | 560 mm | 581 mm | 586 mm | 592 mm | 598 mm | 604 mm |
| Reach | 370 mm | 383 mm | 391 mm | 409 mm | 422 mm | 440 mm |
| Top Tube Length | 530 mm | 555 mm | 570 mm | 590 mm | 610 mm | 630 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 95 mm | 115 mm | 121 mm | 127 mm | 133 mm | 140 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1033 mm | 1049 mm | 1058 mm | 1079 mm | 1094 mm | 1113 mm |
| Standover Height | 674 mm | 687 mm | 734 mm | 743 mm | 781 mm | 811 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
About this model
ATX 2 completes the Giant Atx model. Giant released 16 bikes variations of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Model range prices
Giant ATX 2 2017 is the most affordable bike of this model and has a price of 465$. On the other hand, Giant ATX Lite 2017, is the most expensive and costs 485$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Commuter bikes
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, you could also get a good Commuter bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2017 and its price was 465$. If we compare this with the average Commuter bike cost we notice that the price is 63.87% smaller.
ATX 2 components
Fork
The SunTour XCT is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
As for the wheels, Giant ATX 2 2017, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
When you want to stop the bike in time, the brakes are vital. The ATX 2 has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
