Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Altus, Shimano -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum
Suspension Fork
ALUXX-grade aluminum with low-rider rack mounts
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano M310
Front Derailleur
Shimano M191
Shift Levers
Shimano EF51
Cassette
Shimano HG31 11x34, 8-speed
Crank
SR XCE, 28/38/48
Bottom Bracket
SR Suntour, threaded
Chain
KMC Z8
Pedals
Platform
Wheels
Front Hub
Alloy, 32h
Rear Hub
Alloy, 32h
Rims
Giant Alloy, Double-wall
Spokes
Stainless Steel, 14g
Tires
CST Maverick Lite, 27.5x1.95
Brakes
Brakes
Tektro, mechanical disc, 160mm
Brake Levers
Shimano EF500
Cockpit
Stem
Giant Sport
Handlebar
Giant Sport, Low Rise, 31.8mm
Seat
Saddle
Giant Connect Upright
Seatpost
Giant Sport, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.514 mm | 1.517 mm | 1.499 mm | 1.447 mm | 1.417 mm | 1.373 mm |
| Stack | 560 mm | 581 mm | 586 mm | 592 mm | 598 mm | 604 mm |
| Reach | 370 mm | 383 mm | 391 mm | 409 mm | 422 mm | 440 mm |
| Top Tube Length | 530 mm | 555 mm | 570 mm | 590 mm | 610 mm | 630 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° | 72.5 ° |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 95 mm | 115 mm | 121 mm | 127 mm | 133 mm | 140 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1033 mm | 1049 mm | 1058 mm | 1079 mm | 1094 mm | 1113 mm |
| Standover Height | 674 mm | 687 mm | 734 mm | 743 mm | 781 mm | 811 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
About this model
ATX Lite belongs to the Giant Atx model. There are 16 bikes that carry this model name. Take a sneak peek at all Giant Atx bikes models from 2017, by clicking here.
Model range prices
Giant ATX 2 2017 is the cheapest bike model and costs 465$. Giant ATX Lite 2017 is the most expensive one and costs 485$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Commuter bikes average price
According to our math, the average price for a trustworthy Commuter bike is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Giant ATX Lite price was 485$. If we compare this with the average Commuter bike cost we notice that the price is 57.11% smaller.
Overview of components
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
The ATX Lite 2017 bike is equipped with aluminum wheels when leaving the factory. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
When you want to stop the bike in time, the brakes are vital. The ATX Lite has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
