Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" / 650b -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XXS
152cm - 158cm
XS
156cm - 163cm
SM
161cm - 171cm
MD
169cm - 176cm
LG
174cm - 186cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
SR Suntour XCT 26/27.5, 100mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano Tourney
Shift Levers
Shimano EF41, 3x7
Cassette
Shimano MF-TZ500, 14x34
Crank
ProWheel forged, 24/34/42
Bottom Bracket
cartridge
Chain
KMC Z51
Pedals
N/A
Wheels
Rims
Giant GX28 disc wheelset
Tires
Giant Quickcross 27.5x2.1/26x2.1
Brakes
Brakes
TKB-172
Brake Levers
Shimano EF41
Cockpit
Stem
Giant Sport alloy, 10-degree
Handlebar
Giant Sport XC, 31.8, alloy
Seat
Saddle
Giant Connect (upright)
Seatpost
Giant Sport, 30.9x350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.42 mm | 1.44 mm | 1.46 mm | 1.5 mm | 1.51 mm |
| Front Center | 647 mm | 658 mm | 650 | 661 mm | 684 mm | 706 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 92 mm | 92 mm | 92 mm | 92 mm | 92 mm | 92 mm |
| Stack | 557 mm | 566 mm | 582 mm | 596 mm | 629 mm | 652 mm |
| Reach | 391 mm | 399 mm | 404 mm | 409 mm | 419 mm | 432 mm |
| Top Tube Length | 556 mm | 566 mm | 576 mm | 591 mm | 611 mm | 631 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 350 mm | 385 mm | 420 mm | 455 mm | 505 mm | 535 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 105 mm | 95 mm | 110 mm | 145 mm | 170 mm |
| Chainstay Length | 421 mm | 421 mm | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1066 mm | 1077 mm | 1081 mm | 1092 mm | 1115 mm | 1137 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 689 mm | 711 mm | 722 mm | 748 mm | 790 mm | 815 mm |
| Wheels | 26" | 26" | 650 | 650 | 650 | 650 |
| Rider Min Height | 152 cm | 156 cm | 161 cm | 169 cm | 174 cm | 184 cm |
| Rider Max Height | 158 cm | 163 cm | 171 cm | 176 cm | 186 cm | 193 cm |
Model Overview
ATX 2 belongs to the Giant Atx model. Giant released 16 bikes variations of this model so far. Take a sneak peek at all Giant Atx bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Giant ATX 3 2019 has a starting price of 410$. Giant ATX 2 2019 on the other hand is the most expensive at 475$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Commuter bikes
According to our calculations, the average cost of a Commuter bike that is reliable is 762$. However, even though the average price of a Commuter bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Giant released this model in 2019, its price was 475$. In conclusion, this bike price is 60.42% lower than the price of the average Commuter bike.
Overview of components
Fork
The ATX 2 comes factory-installed with the SunTour XCT fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the ATX 2 bike is equipped with the 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The ATX 2 has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
ATX 2 comes in 6 sizes, that range from 152 cm – 193 cm (4.99 ft – 6.33 ft). In conclusion, finding one for you shouldn’t be a problem.
