Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" / 650b -
Travel Front 100mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 2 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
152cm - 158cm
XS
156cm - 163cm
SM
161cm - 171cm
MD
169cm - 176cm
LG
174cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum, disc
Suspension Fork
SR Suntour XCE 26/27.5", 100mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Tourney
Front Derailleur
Shimano M315
Shift Levers
Shimano SL-M315
Cassette
Shimano MF-TZ500, 14x34, 7-Speed
Crank
Prowheel forged, 22/36
Bottom Bracket
cartridge
Chain
KMC Z7
Pedals
Platform MTB
Wheels
Front Hub
Alloy 32h, Disc
Rear Hub
Alloy 32h, Disc
Rims
Giant GX03, Disc, Double Wall, [XXS-S] 26", [M-XL] 27.5", (21mm inner)
Spokes
stainless, 14g
Tires
Giant Quickcross, [XXS-S] 26x2.1", [M-XL] 27.5x2.1", 30 TPI
Brakes
Brakes
Tektro M275/276 Hydraulic Disc, 160mm
Brake Levers
Tektro M275/276
Cockpit
Stem
Giant Sport, alloy, 10-degree
Handlebar
Giant Connect XC, 31.8
Seat
Saddle
Giant Sport Comfort
Seatpost
Giant Sport, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.42 mm | 1.44 mm | 1.46 mm | 1.5 mm |
| Front Center | 647 mm | 658 mm | 669 mm | 661 mm | 684 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 92.5 mm | 92.5 mm | 92.5 mm | 92.5 mm | 92.5 mm |
| Stack | 557 mm | 566 mm | 580 mm | 596 mm | 629 mm |
| Reach | 391 mm | 399 mm | 404 mm | 409 mm | 419 mm |
| Top Tube Length | 556 mm | 566 mm | 576 mm | 591 mm | 611 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 350 mm | 385 mm | 420 mm | 455 mm | 505 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 105 mm | 120 mm | 110 mm | 145 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 436 mm | 436 mm |
| Wheelbase | 1066 mm | 1077 mm | 1088 mm | 1092 mm | 1115 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 50 mm | 50 mm |
| Standover Height | 689 mm | 711 mm | 724 mm | 748 mm | 790 mm |
| Wheels | 26" | 26" | 26" | 650 | 650 |
| Rider Min Height | 152 cm | 156 cm | 161 cm | 169 cm | 174 cm |
| Rider Max Height | 158 cm | 163 cm | 171 cm | 176 cm | 185 cm |
About this model
ATX 2 is part of the Giant Atx model. Giant launched 16 bikes of this model so far. Take a sneak peek at all Giant Atx bikes models from 2020, by clicking here.
Model range prices
Giant ATX 3 2020 is the most affordable bike of this model and has a price of 430$. On the other hand, Giant ATX 1 2020, is the most expensive and costs 546$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Commuter bikes
If you want to purchase a solid Commuter bike, it is important to know that the average cost is 762$. However, you could also get a good Commuter bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Giant released this model in 2020, its price was 455$. Doing a quick comparison, we notice that ATX 2 price is 67.47% lower than the average cost of a Commuter bike.
Average weight for Commuter bikes
The average weight for Commuter bikes is 14.29 kg (31.5 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
slightly lighter than average, ATX 2 has a weight of 14 kg (30.86 lbs). In conclusion, the average Commuter bike weighs 2.07% more than ATX 2.
ATX 2 components
Fork
This bike has the SunTour fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When it comes to wheels, the ATX 2 bike is equipped with the 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant ATX 2 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Giant ATX 2 bike has 5 sizes, in the range of 152 cm – 185 cm (4.99 ft – 6.07 ft). In short, you can easily find one that suits you.
