Giant Dirt-E+ 1 Pro 2018
2018 E-bike
Estimate price |
3,930$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Revelation RC
-
Groupset XT, SLX -
Suspension Hardtail -
Motor Giant 250W 80Nm mid-drive -
Battery Giant EnergyPak 500, 36V 13.8Ah Rechargeable Lithium-Ion -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum
Suspension Fork
Rock Shox Revelation 35 RL 27,5+ 120mm travel, Tapered 1½ - 1?" steerer,110x15QR, lockout
Drivetrain
Rear Derailleur
Shimano XT Shadow Plus
Shift Levers
Shimano SLX 11sp
Cassette
Shimano HG-M7000, 11-46T, 11-sp
Crank
Praxis Works 36T Cold Forged 4130 premium plate steel Wavetm chainring, custom crankset, Boost 1x spider
Chain
KMC X.11e, EcoProteq, e-bike specific
Pedals
Aluminum Platform
Wheels
Front Hub
Giant eTracker Boost, Sealed Cartridge bearing, IS 6-bolt, [F] 110x15 [R] 148x12mm Thru-axle, e-bike optimized
Rear Hub
Giant eTracker Boost, Sealed Cartridge bearing, IS 6-bolt, [F] 110x15 [R] 148x12mm Thru-axle, e-bike optimized
Rims
Giant GE35, Tubeless ready, 27.5" 35mm aluminum, e-bike optimized
Spokes
Giant eTracker Boost, Sealed Cartridge bearing, IS 6-bolt[F] 110x15mm, 28h,[R] 148x12mm Thru-axle, e-bike optimized, 32h
Tires
Maxxis Forekaster 27.5x2.6, foldable, Exo protect, Tubeless
Brakes
Brakes
Shimano BR-MT500 180/200mm Disc
Brake Levers
Shimano BL-MT500 i-spec II
Cockpit
Stem
Giant Connect [50 S, 60 M/L, 70XL]
Handlebar
Giant Connect Trail 780x31,8mm
Seat
Saddle
Giant Contact neutral
Seatpost
Giant Contact Switch, remote height adjust [100 XS/S/M, 125 L, 150 XL]
Motor & Battery
Motor
Giant SyncDrive Pro
Battery
Giant EnergyPak 500, 36V 13.8Ah Rechargeable Lithium-Ion
Remote
Giant RideControl EVO, grip launch control with walk assist, mini USB charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.47 mm | 1.46 mm | 1.44 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 667 mm | 688 mm | 710 mm | 731 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 99 mm | 99 mm | 99 mm | 99 mm |
| Stack | 604 mm | 609 mm | 628 mm | 642 mm |
| Reach | 396 mm | 415 mm | 429 mm | 445 mm |
| Top Tube Length | 580 mm | 600 mm | 620 mm | 640 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 405 mm | 455 mm | 505 mm | 535 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 110 mm | 115 mm | 135 mm | 150 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1138 mm | 1159 mm | 1181 mm | 1202 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 758 mm | 765 mm | 792 mm | 796 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Dirt-E+ 1 Pro belongs to the Giant E Dirt Eplus model. Giant released 4 e-bikes variations of this model so far. Take a sneak peek at all Giant E Dirt Eplus e-bikes models from 2018, by clicking here.
Model range prices
Giant Dirt-E+ 2 2018 is the cheapest e-bike model and costs 2600$. Giant Dirt-E+ 0 Pro 2018 is the most expensive one and costs 4340$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail e-bikes average price
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2018 for 3930$. In conclusion, this e-bike price is 16.79% higher than the price of the average Trail e-bike.
Overview of components
Fork
The RockShox Revelation RC is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Dirt-E+ 1 Pro are the 27.5″ aluminum type. These wheels will provide you with more control over the e-bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant Dirt-E+ 1 Pro is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Giant Dirt-E+ 1 Pro comes with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
