Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio, Altus -
Suspension Hardtail -
Motor Yamaha 250W 50Nm mid-drive -
Battery EnergyPak 500 -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
169cm - 179cm
LG
176cm - 186cm
XL
183cm - 193cm
XXL
190cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX aluminum, Overdrive 1½ - 1?" head tube, integrated KS18A kickstand mount
Suspension Fork
SR Suntour NEX DS 63mm travel
Rear Shock
n/a
Drivetrain
Rear Derailleur
Shimano Alivio, 9-speed
Front Derailleur
n/a
Shift Levers
Shimano Altus
Cassette
Shimano CS-HG200, 11-36T, 9-Speed
Crank
Forged Alloy minimal Q-factor, 42T
Bottom Bracket
n/a
Chain
KMC e.9 Sport, e-bike optimized
Pedals
Aluminum Platform
Wheels
Front Hub
Giant eTracker, [F] 100x9mm QR [R] 135mm QR
Rear Hub
Giant eTracker, [F] 100x9mm QR [R] 135mm QR
Rims
Giant eX 2, Tubeless Ready, 622x21 aluminium
Spokes
Stainless steel
Tires
Giant Crosscut Gravel 2, 700x50c, Tubeless Ready
Brakes
Brakes
Tektro HD-M275, hydraulic disc, 180mm [F], 160mm [R]
Brake Levers
Tektro HD-M275
Cockpit
Stem
Giant Contour TDS 816-8FOV (S/M:80mm L/XL/XXL 100mm)
Handlebar
Giant Connect Riser 31.8x690mm
Grips
Giant Contact
Seat
Saddle
Selle Royal Vivo Ergo Moderate
Seatpost
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
Motor & Battery
Motor
SyncDrive Core, 50Nm, powered by Yamaha
Battery
EnergyPak 500
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.55 mm | 1.52 mm | 1.5 mm | 1.5 mm |
| Front Center | 664 mm | 673 mm | 694 mm | 714 mm | 714 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 91 mm | 91 mm | 91 mm | 91 mm | 91 mm |
| Stack | 611 mm | 620 mm | 634 mm | 649 mm | 649 mm |
| Reach | 396 mm | 401 mm | 417 mm | 433 mm | 433 mm |
| Top Tube Length | 571 mm | 591 mm | 611 mm | 631 mm | 651 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 435 mm | 485 mm | 535 mm | 585 mm | 610 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 130 mm | 140 mm | 155 mm | 170 mm | 185 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1113 mm | 1122 mm | 1143 mm | 1164 mm | 1164 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 737 mm | 765 mm | 797 mm | 843 mm | 843 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 176 cm | 183 cm | 190 cm |
| Rider Max Height | 172 cm | 179 cm | 186 cm | 193 cm | 200 cm |
Model Overview
Explore E+, 4 GTS belongs to the Giant E Explore model. Giant launched 72 e-bikes of this model so far. You can easily view all of the Giant E Explore e-bikes models from 2023, here.
Model range prices
Giant Explore E+, 3 STA 2023 is the cheapest e-bike model and costs 2819$. Giant Explore E+, Pro 0 STA 2023 is the most expensive one and costs 5308$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Hybrid e-bikes
If you want to purchase a solid Hybrid e-bike, it is important to know that the average cost is 2480$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Explore E+, 4 GTS components
Fork
The Suntour NEX is included from the factory. It has a travel distance of 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
As for the wheels, Giant Explore E+, 4 GTS 2023, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Giant Explore E+, 4 GTS e-bike has 5 sizes, in the range of 162 cm – 200 cm (5.31 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
