Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 140mm -
Fork RockShox Lyrik
-
Groupset EX1, Praxis -
Suspension Full -
Motor Yamaha 500W 80Nm mid-drive -
Battery Giant EnergyPak500, 36V 13.8Ah Rechargeable Lithium-Ion -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, 140mm Maestro suspension
Suspension Fork
RockShox Lyrik RCT3, 15mm thru-axle, OverDrive, 130-160mm travel
Rear Shock
RockShox SuperDeluxe RCT3, Debonair, Trunnion mount
Drivetrain
Rear Derailleur
SRAM EX1 e-MTB specific
Front Derailleur
MRP 1x Carbon D-Mount mini-guide
Shift Levers
SRAM EX1 e-MTB specific
Cassette
SRAM EX1, e-MTB specific, 11x48, 8-speed
Crank
Custom forged, Praxis Works 36T
Bottom Bracket
N/A
Chain
SRAM PC1051
Pedals
Aluminum Platform
Wheels
Front Hub
DT Swiss Spline One 240s, [F] Boost 110x15 [R] Boost 148x12
Rear Hub
DT Swiss Spline One 240s, [F] Boost 110x15 [R] Boost 148x12
Rims
DT Swiss EX 1501 Spline One
Spokes
DT Swiss Competition, 14/15g
Tires
Schwalbe Nobby Nic, 27.5x2.60, Evo Foldable, SnakeSkin sidewall, [F] Trail Star, [R] Pace Star
Brakes
Brakes
SRAM Guide RSC, 200mm
Brake Levers
SRAM Guide RSC
Cockpit
Stem
Giant Contact
Handlebar
Contact SL DH
Seat
Saddle
Giant Contact SL Upright, SST tubular rails
Seatpost
Giant Contact SL Switch Trail, remote height adjust
Motor & Battery
Motor
Giant SyncDrive Sport, 80Nm, 500W, Powered by Yamaha
Battery
Giant EnergyPak500, 36V 13.8Ah Rechargeable Lithium-Ion
Remote
Giant RideControl EVO, grip launch control with walk assist, mini USB charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.52 mm | 1.49 mm | 1.47 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm | 343 mm |
| Front Center | 680 mm | 705 mm | 727 mm | 754 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 103 mm | 103 mm | 102 mm | 102 mm |
| Stack | 607 mm | 607 mm | 621 mm | 639 mm |
| Reach | 375 mm | 400 mm | 416 mm | 435 mm |
| Top Tube Length | 562 mm | 587 mm | 607 mm | 632 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 431 mm | 450 mm | 500 mm | 530 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 125 mm | 125 mm | 140 mm | 160 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1140 mm | 1165 mm | 1187 mm | 1214 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Full-E+ 0 SX completes the Giant E Full Eplus model. Giant released 5 e-bikes variations of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Model range prices
The most economical model, the Giant Full-E+ 1 2017 has a starting price of 5300$. Giant Full-E+ 0 SX 2017 on the other hand is the most expensive at 7700$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 7700$. Comparing the average cost of a Trail e-bike to this one, you will see that Full-E+ 0 SX price is 128.83% higher.
Overview of components
Fork
Giant Full-E+ 0 SX 2017 e-bike is equipped with the RockShox Lyrik fork, and has 160mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Giant Full-E+ 0 SX e-bike has the RockShox SuperDeluxe RCT3 model installed, and has a travel of 140mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the Full-E+ 0 SX e-bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Full-E+ 0 SX comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Full-E+ 0 SX comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Giant Full-E+ 0 SX includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
