Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork Fox Performance Float 34
-
Groupset XT, SLX -
Suspension Full -
Motor Yamaha 500W 80Nm mid-drive -
Battery Giant EnergyPak500, 36V 13.8Ah Rechargeable Lithium-Ion -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, 140mm Maestro suspension
Suspension Fork
Fox 34 Float Performance, 15mm thru-axle, OverDrive, 140mm travel
Rear Shock
Fox Float Performance DPS, Trunnion mount
Drivetrain
Rear Derailleur
Shimano XT, Shadow+
Front Derailleur
Shimano XT
Shift Levers
Shimano SLX
Cassette
Shimano HG-M7000 11x40, 11-speed
Crank
Custom forged, 28/38
Bottom Bracket
N/A
Chain
KMC X.11e EcoProteQ
Pedals
Alloy Platform
Wheels
Front Hub
Giant Performance Tracker Disc, [F] Boost 110x15mm, [R] Boost 148x12mm
Rear Hub
Giant Performance Tracker Disc, [F] Boost 110x15mm, [R] Boost 148x12mm
Rims
Giant Alloy, Double wall
Spokes
Stainless Steel
Tires
Schwalbe Rocket Ron, 27.5x2.60, Evo Foldable, SnakeSkin sidewall, [F] Trail Star, [R] Pace Star
Brakes
Brakes
Shimano M615, hydraulic disc, 200mm
Brake Levers
Shimano M615
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect Trail, 31.8mm
Seat
Saddle
Giant Contact Upright
Seatpost
Giant Contact SL Switch Trail, remote height adjust
Motor & Battery
Motor
Giant SyncDrive Sport, 80Nm, 500W, Powered by Yamaha
Battery
Giant EnergyPak500, 36V 13.8Ah Rechargeable Lithium-Ion
Remote
Giant RideControl EVO, grip launch control with walk assist, mini USB charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.52 mm | 1.49 mm | 1.47 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm | 343 mm |
| Front Center | 680 mm | 705 mm | 727 mm | 754 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 103 mm | 103 mm | 102 mm | 102 mm |
| Stack | 607 mm | 607 mm | 621 mm | 639 mm |
| Reach | 375 mm | 400 mm | 416 mm | 435 mm |
| Top Tube Length | 562 mm | 587 mm | 607 mm | 632 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 431 mm | 450 mm | 500 mm | 530 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 125 mm | 125 mm | 140 mm | 160 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1140 mm | 1165 mm | 1187 mm | 1214 mm |
| Bottom Bracket Drop | 12 mm | 12 mm | 12 mm | 12 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Full-E+ 1 belongs to the Giant E Full Eplus model. Giant launched 5 e-bikes of this model so far. You can easily view all of the Giant E Full Eplus e-bikes models from 2017, here.
Model range prices
Giant Full-E+ 1 2017 is the most affordable e-bike of this model and has a price of 5300$. On the other hand, Giant Full-E+ 0 SX 2017, is the most expensive and costs 7700$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail e-bikes average price
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2017 for 5300$. In conclusion, this e-bike price is 57.5% higher than the price of the average Trail e-bike.
Overview of components
Fork
This e-bike has the Fox Performance Float 34 fork installed. The fork’s travel is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Full-E+ 1 has a rear shock with a travel of 140mm. The model Fox Float Performance DPS is the one installed in this e-bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
As for the wheels, Giant Full-E+ 1 2017, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant Full-E+ 1 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Giant Full-E+ 1 e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
The Giant model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
