Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset X4, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
SR Suntour XCM V3 w/Lockout, 100mm Travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X4
Front Derailleur
Shimano M310
Shift Levers
SRAM X4, 3x8 Speed
Cassette
SRAM PG 830 11x32, 8-Speed
Crank
SR Suntour NEX w/Chainguard, 24/34/42
Bottom Bracket
Suntour, Sealed Cartridge
Chain
KMC Z8
Pedals
Alloy Platform
Wheels
Front Hub
Formula Disc, 32h
Rear Hub
Formula Disc, 32h
Rims
Giant Alloy, Double Wall
Spokes
Stainless Steel, 14g
Tires
Giant Sport, 26x2.1
Brakes
Brakes
Tektro Novela Mechanical Disc, 160mm
Brake Levers
Tektro Novela Mechanical Disc
Cockpit
Stem
Giant Sport
Handlebar
Giant Sport, Low Rise, 31.8
Seat
Saddle
Giant Sport Trail
Seatpost
Giant Sport, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Top Tube Length | 541 mm | 569 mm | 579 mm | 592 mm | 617 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72 ° | 72 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 119 mm | 130 mm | 145 mm | 160 mm | 180 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1031 mm | 1057 mm | 1077 mm | 1090 mm | 1105 mm |
| Standover Height | 724 mm | 732 mm | 767 mm | 798 mm | 810 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Revel 1 is a Giant Revel model. 43 bikes variations carry this model name so far. Take a sneak peek at all Giant Revel bikes models from 2013, by clicking here.
Model range prices
Giant Revel Jr. Boys 20 2013 is the most affordable bike of this model and has a price of 220$. On the other hand, Giant Revel 29er 0 2013, is the most expensive and costs 700$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Giant Revel 1 price was 525$. Comparing the average cost of a Crosscountry bike to this one, you will see that Revel 1 price is 262.86% lower.
Revel 1 components
Fork
Giant Revel 1 2013 bike is equipped with the SunTour XCM fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When it comes to wheels, the Revel 1 bike is equipped with the 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant Revel 1 is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Giant Revel 1 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
