Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset X4, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Butted Aluminum
Suspension Fork
SR Suntour XCM V3 w/ Preload Adjust, 100mm Travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X.4
Front Derailleur
Shimano Altus M310
Shift Levers
SRAM X.4, Trigger
Cassette
SRAM PG820 11x32, 8-Speed
Crank
SR Suntour XCT-V2, 22/32/42
Bottom Bracket
SR Cartridge
Chain
KMC Z72
Pedals
Alloy Platform
Wheels
Front Hub
Formula Disc, 32h
Rear Hub
Formula Disc, 32h
Rims
Giant XC Alloy, Double Wall
Spokes
Stainless Steel, 14g
Tires
Kenda Small Block Eight, 26x2.1
Brakes
Brakes
Tektro I.O. Disc
Brake Levers
Tektro Alloy, 2 Finger
Cockpit
Stem
Giant Sport Alloy
Handlebar
Giant for Women Sport Alloy, Low Rise, 31.8mm
Seat
Saddle
Giant Sport MTB, Women's
Seatpost
Giant Sport Alloy, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Top Tube Length | 531 mm | 556 mm | 574 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 124 mm | 135 mm | 150 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1024 mm | 1050 mm | 1068 mm |
| Standover Height | 709 mm | 721 mm | 749 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
Model Overview
Revel 1 W belongs to the Giant Revel model. Giant released 43 bikes variations of this model so far. Check out the entire range from 2011 of this model, by clicking this link.
Model range prices
Giant Revel 2 W 2011 is the most affordable bike of this model and has a price of 390$. On the other hand, Giant Revel 0 2011, is the most expensive and costs 670$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Giant Revel 1 W price was 510$. Doing a quick comparison, we notice that Revel 1 W price is 273.53% smaller than the average cost of a Crosscountry bike.
Overview of components
Fork
The Revel 1 W comes factory-installed with the SunTour XCM fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The wheels on Revel 1 W are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
This bike is available in 3 sizes. They vary from 151 cm – 179 cm (4.95 ft – 5.87 ft). In short, it won’t be difficult to find the right one for you.
