Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM Short
159cm - 171cm
SM Long
159cm - 171cm
MD Short
169cm - 181cm
MD Long
169cm - 181cm
MD/LG Short
174cm - 186cm
MD/LG Long
174cm - 186cm
LG Short
179cm - 191cm
LG Long
179cm - 191cm
XL Short
189cm - 200cm
XL Long
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminium, 12x142mm thru-axle, disc, flip chip dropout
Suspension Fork
Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano GRX RX-820
Front Derailleur
Shimano GRX RX-820
Shift Levers
Shimano GRX RX-610, 2x12
Cassette
Shimano 105, 11x34
Crank
FSA Omega Modular AGX+, 32/48 S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Bottom Bracket
FSA Mega EXO
Chain
KMC X12L-1
Pedals
PEDALS NOT SUPPLIED
Wheels
Front Hub
Giant alloy, 12mm thru-axle
Rear Hub
Giant alloy, 12mm thru-axle
Rims
Giant S-X2 Disc wheelset, alloy
Spokes
Stainless steel
Tires
Maxxis Rambler, 700x40c, tubeless
Brakes
Brakes
Shimano GRX RX-410 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
Brake Levers
Shimano GRX RX-610 hydraulic
Cockpit
Stem
Giant Contact, 8-degree S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
Handlebar
Giant Contact XR D-Fuse, 31.8mm S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
Grips
cork tape with gel
Seat
Saddle
Giant Approach
Seatpost
Giant D-Fuse, alloy, 14mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM Short | SM Long | MD Short | MD Long | MD/LG Short | MD/LG Long | LG Short | LG Long | XL Short | XL Long |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.496 mm | 1.496 mm | 1.514 mm | 1.514 mm | 1.54 mm | 1.54 mm | 1.552 mm | 1.552 mm | 1.548 mm | 1.548 mm |
| Bottom Bracket Height | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm |
| Front Center | 608 mm | 608 mm | 613 mm | 613 mm | 618 mm | 618 mm | 628 mm | 628 mm | 643 mm | 644 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 72 mm | 75 mm | 68 mm | 72 mm | 65 mm | 68 mm | 65 mm | 68 mm | 65 mm | 68 mm |
| Stack | 570 mm | 570 mm | 586 mm | 586 mm | 602 mm | 602 mm | 616 mm | 616 mm | 630 mm | 630 mm |
| Reach | 381 mm | 381 mm | 387 mm | 387 mm | 391 mm | 391 mm | 397 mm | 397 mm | 407 mm | 407 mm |
| Top Tube Length | 550 mm | 550 mm | 560 mm | 560 mm | 575 mm | 575 mm | 585 mm | 585 mm | 600 mm | 600 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 450 mm | 470 mm | 470 mm | 490 mm | 490 mm | 510 mm | 510 mm | 530 mm | 530 mm |
| Head Tube Angle | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 135 mm | 135 mm | 150 mm | 150 mm | 165 mm | 165 mm | 180 mm | 180 mm | 195 mm | 195 mm |
| Chainstay Length | 430 mm | 440 mm | 430 mm | 440 mm | 430 mm | 440 mm | 430 mm | 440 mm | 430 mm | 440 mm |
| Wheelbase | 1025 mm | 1035 mm | 1030 mm | 1040 mm | 1035 mm | 1045 mm | 1045 mm | 1055 mm | 1061 mm | 1071 mm |
| Bottom Bracket Drop | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm |
| Standover Height | 734 mm | 741 mm | 752 mm | 759 mm | 769 mm | 776 mm | 786 mm | 793 mm | 801 mm | 810 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 159 cm | 159 cm | 169 cm | 169 cm | 174 cm | 174 cm | 179 cm | 179 cm | 189 cm | 189 cm |
| Rider Max Height | 171 cm | 171 cm | 181 cm | 181 cm | 186 cm | 186 cm | 191 cm | 191 cm | 200 cm | 200 cm |
Model Overview
Revolt 0 is part of the Giant Revolt model. Giant launched 69 bikes of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
The most economical model, the Giant Revolt 2 2024 has a starting price of 1228$. Giant Revolt X, Advanced Pro 0 2024 on the other hand is the most expensive at 7000$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2024 and its price was 2191$. If we compare this with the average Gravel bike cost we notice that the price is 12.37% lower.
Revolt 0 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the Revolt 0 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Revolt 0 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Revolt 0 comes in 10 sizes, that range from 159 cm – 200 cm (5.22 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
