Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 400, Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS Short
155cm - 166cm
XS Long
155cm - 166cm
SM Short
159cm - 171cm
SM Long
159cm - 171cm
MD Short
169cm - 181cm
MD Long
169cm - 181cm
MD/LG
174cm - 186cm
MD/LG
174cm - 186cm
LG Short
179cm - 191cm
LG Long
179cm - 191cm
XL Short
189cm - 200cm
XL Long
189cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-grade aluminum, 12x142mm thru-axle, disc, flip chip dropout
Suspension Fork
Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano GRX RX-400
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano GRX RX-400, 2x10
Cassette
Shimano HG500, 11x34
Crank
FSA Omega Adventure, 32/48 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Bottom Bracket
FSA Mega EXO
Chain
KMC X10 with Missing Link
Pedals
N/A
Wheels
Front Hub
Giant alloy, 12mm thru-axle
Rear Hub
Giant alloy, 12mm thru-axle
Rims
Giant S-X2 Disc wheelset, alloy
Spokes
stainless
Tires
Giant CrossCut AT 2, 700x38c, tubeless
Brakes
Brakes
Shimano GRX RX-400 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
Brake Levers
Shimano GRX RX-400 hydraulic
Cockpit
Stem
Giant Contact, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
Handlebar
Giant Contact XR D-Fuse, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
Grips
cork tape with gel
Seat
Saddle
Giant Approach
Seatpost
Giant D-Fuse, alloy, 14mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS Short | XS Long | SM Short | SM Long | MD Short | MD Long | MD/LG | MD/LG | LG Short | LG Long | XL Short | XL Long |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.46 mm | 1.5 mm | 1.5 mm | 1.52 mm | 1.52 mm | 1.55 mm | 1.55 mm | 1.56 mm | 1.56 mm | 1.55 mm | 1.55 mm |
| Bottom Bracket Height | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm | 269 mm | 268 mm |
| Front Center | 612 mm | 612 mm | 608 mm | 608 mm | 613 mm | 613 mm | 618 mm | 618 mm | 628 mm | 628 mm | 643 mm | 644 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 78 mm | 82 mm | 72 mm | 75 mm | 68 mm | 72 mm | 65 mm | 68 mm | 65 mm | 68 mm | 65 mm | 68 mm |
| Stack | 552 mm | 552 mm | 566 mm | 566 mm | 582 mm | 582 mm | 598 mm | 598 mm | 612 mm | 612 mm | 626 mm | 626 mm |
| Reach | 377 mm | 377 mm | 377 mm | 377 mm | 383 mm | 383 mm | 387 mm | 387 mm | 393 mm | 393 mm | 403 mm | 403 mm |
| Top Tube Length | 536 mm | 536 mm | 546 mm | 546 mm | 556 mm | 556 mm | 571 mm | 571 mm | 581 mm | 581 mm | 596 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 430 mm | 450 mm | 450 mm | 470 mm | 470 mm | 490 mm | 490 mm | 510 mm | 510 mm | 530 mm | 530 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 125 mm | 125 mm | 135 mm | 135 mm | 150 mm | 150 mm | 165 mm | 165 mm | 180 mm | 180 mm | 195 mm | 195 mm |
| Chainstay Length | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm | 426 mm | 436 mm |
| Wheelbase | 1025 mm | 1035 mm | 1021 mm | 1031 mm | 1026 mm | 1036 mm | 1031 mm | 1041 mm | 1041 mm | 1051 mm | 1057 mm | 1067 mm |
| Bottom Bracket Drop | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm | 80 mm | 81 mm |
| Standover Height | 713 mm | 720 mm | 730 mm | 737 mm | 748 mm | 755 mm | 765 mm | 772 mm | 782 mm | 789 mm | 797 mm | 806 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 155 cm | 159 cm | 159 cm | 169 cm | 169 cm | 174 cm | 174 cm | 179 cm | 179 cm | 189 cm | 189 cm |
| Rider Max Height | 166 cm | 166 cm | 171 cm | 171 cm | 181 cm | 181 cm | 186 cm | 186 cm | 191 cm | 191 cm | 200 cm | 200 cm |
About this model
Revolt 1 is part of the Giant Revolt model. Giant released 68 bikes variations of this model so far. You can easily view all of the Giant Revolt bikes models from 2024, here.
Model range prices
The most economical model, the Giant Revolt 2 2024 has a starting price of 1229$. Giant Revolt X, Advanced Pro 0 2024 on the other hand is the most expensive at 7000$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Giant released this model in 2024, its price was 1590$. In conclusion, this bike price is 54.84% lower than the price of the average Gravel bike.
Revolt 1 components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Giant Revolt 1 2024, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Revolt 1 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 12 sizes. They vary from 155 cm – 200 cm (5.09 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
