Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, FSA -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum w/ rack mounts
Suspension Fork
Advanced-grade composite, with alloy OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Claris
Front Derailleur
Shimano Claris
Shift Levers
Shimano Claris
Cassette
Shimano HG51 11x32, 8-speed
Crank
FSA Tempo, 30/39/50
Bottom Bracket
Shimano, Sealed
Chain
KMC Z8
Pedals
N/A
Wheels
Front Hub
Alloy Disc, 32h
Rear Hub
Alloy Disc, 32h
Rims
Giant Alloy, Double wall
Spokes
Stainless Steel, 14g
Tires
Schwalbe Smart Sam Performance, 700x35
Brakes
Brakes
Tektro Mira, Mechanical disc, [F] 160mm, [R] 140mm
Brake Levers
Shimano R460 w/ Tektro RL721 sub lever
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect XR Ergo-Control, 31.8mm
Seat
Saddle
Giant Connect, Forward
Seatpost
Giant Connect, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Top Tube Length | 554 mm | 564 mm | 569 mm | 579 mm | 584 mm |
| Seat Tube Angle | 72 ° | 72 ° | 71.5 ° | 71 ° | 71 ° |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 130 mm | 150 mm | 165 mm | 178 mm | 196 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1041 mm | 1046 mm | 1046 mm | 1052 mm | 1057 mm |
| Standover Height | 729 mm | 749 mm | 765 mm | 780 mm | 798 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
Model Overview
Revolt 3 is a Giant Revolt model. 68 bikes variations carry this model name so far. You can get a glimpse at all models from 2015, by clicking on this link.
Model range prices
Giant Revolt 3 2015 is the cheapest bike model and costs 1045$. Giant Revolt 0 2015 is the most expensive one and costs 2775$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2015 for 1045$. If we compare this with the average Gravel bike cost we notice that the price is 135.6% smaller.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Revolt 3 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Revolt 3 has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Revolt 3 comes in 5 sizes, that range from 162 cm – 199 cm (5.31 ft – 6.53 ft). In short, you can easily find one that suits you.
