Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX Di2, Shimano -
Suspension Rigid -
Motor Shimano 250W 85Nm mid-drive -
Battery EnergyPak Compact 500Wh EnergyPak Plus range extender compatible -
Drivetrain 1 × 11 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL Aluminium
Suspension Fork
Advanced-Grade Composite, full-composite OverDrive steerer
Rear Shock
-
Drivetrain
Rear Derailleur
Shimano GRX Di2 RX817 (max 42T cassette size)
Front Derailleur
-
Shift Levers
Shimano GRX Di2 ST-RX815 1x11 speed
Cassette
Shimano CS-M5100-11, 11-42, 11-speed
Crank
Shimano FC-EM600 crankarm Shimano SM-CRE80-R, 47T chainring
Bottom Bracket
Integrated into motor
Chain
KMC e.11 Turbo, EcoProteq
Pedals
Aluminum Platform
Wheels
Front Hub
Giant Performance Tracker Road, Sealed Bearing, 12mm thru axle
Rear Hub
Giant Performance Tracker Road, Sealed Bearing, 12mm thru axle
Rims
Giant eX 2, Tubeless Ready, 700c Aluminium
Spokes
Sapim E-Lite [r] Race [f]
Tires
Maxxis Receptor, EXO, Skinwall, 700x40mm, Tubeless
Brakes
Brakes
Shimano BR-RX810, hydraulic disc, 160mm
Brake Levers
Shimano ST-RX815 hydraulic disc
Cockpit
Stem
Giant Contact
Handlebar
Giant Contact XR D-Fuse, 31.8mm, 5° back sweep, flared drop
Grips
Giant Connect tape
Seat
Saddle
Giant Approach
Seatpost
Giant D-Fuse SL, composite
Motor & Battery
Motor
Shimano EP8, 85Nm, up to 400% asssistance
Battery
EnergyPak Compact 500Wh EnergyPak Plus range extender compatible
Charger
EnergyPak 4A smart charger compact
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.57 mm | 1.58 mm | 1.59 mm | 1.59 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 608 mm | 608 mm | 618 mm | 629 mm | 644 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 68.8 mm | 68.8 mm | 68.8 mm | 68.8 mm | 68.8 mm |
| Stack | 572 mm | 586 mm | 600 mm | 614 mm | 628 mm |
| Reach | 379 mm | 374 mm | 380 mm | 386 mm | 396 mm |
| Top Tube Length | 554 mm | 554 mm | 564 mm | 574 mm | 589 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 475 mm | 500 mm | 525 mm | 550 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 135 mm | 150 mm | 165 mm | 180 mm | 195 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1048 mm | 1048 mm | 1058 mm | 1069 mm | 1084 mm |
| Bottom Bracket Drop | 85 mm | 85 mm | 85 mm | 85 mm | 85 mm |
| Standover Height | 741 mm | 746 mm | 797 mm | 809 mm | 829 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
Model Overview
Revolt E+ is a Giant E Revolt model. 6 e-bikes variations carry this model name so far. You can easily view all of the Giant E Revolt e-bikes models from 2021, here.
Model range prices
Giant Revolt E+ Pro 45kmh 2021 is the most affordable e-bike of this model and has a price of 4800$. On the other hand, Giant Revolt E+ 2021, is the most expensive and costs 6446$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel e-bikes average price
If you want to purchase a solid Gravel e-bike, it is important to know that the average cost is 3642$. However, even though the average price of a Gravel e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Giant Revolt E+ price was 6446$. Comparing the average cost of a Gravel e-bike to this one, you will see that Revolt E+ price is 76.99% more expensive.
Revolt E+ components
Fork material
When it comes to the fork, this e-bike has a carbon one, so, it won’t add up to much weight to your e-bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When leaving the production line, the Revolt E+ model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant Revolt E+ is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 5 sizes. They vary from 162 cm – 199 cm (5.31 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
