Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 125mm -
Fork RockShox 35 Silver
-
Groupset Deore, FSA -
Suspension Full -
Motor Yamaha 250W 75Nm mid-drive -
Battery EnergyPak Smart 625, EnergyPak Plus 250Wh range extender compatible -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
163cm - 173cm
MD
170cm - 181cm
LG
178cm - 189cm
XL
186cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-grade aluminum, 125mm travel FlexPoint suspension system, 148x12 rear axle, Universal Derrailleur hanger, 184x44 shock, 1.5~1.8" headset
Suspension Fork
RockShox 35 Silver, 140mm, tapered steerer, 110x15 thru-axle
Rear Shock
SR Suntour Raidon R, 190x45mm, custom tuned
Drivetrain
Rear Derailleur
Shimano Deore LinkGlide, 10-speed
Front Derailleur
MRP HD2 co-moulded chain guide
Shift Levers
Shimano Deore LinkGlide
Cassette
Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed
Crank
FSA Comet E-Bike crank arm setFSA MegaTooth Direct-mount 1X steel 36T
Bottom Bracket
n/a
Chain
Shimano, LinkGlide, CN-LG500
Pedals
Aluminum Platform
Wheels
Front Hub
Giant eTracker Boost, [F] 110x15 [R] 148x12mm
Rear Hub
Giant eTracker Boost, [F] 110x15 [R] 148x12mm
Rims
Giant AM 29", Tubeless ready, 30mm inner width
Spokes
Stainless Steel
Tires
Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO, 60TPI [F]Maxxis Dissector 29X2.40" WT Foldable, TLR, EXO, 60TPI [R]
Brakes
Brakes
Tektro HD-M750 Orion, 4-piston, hydraulic disc, 203mm
Brake Levers
Tektro HD-M750
Cockpit
Stem
Giant Contact
Handlebar
Giant Connect TR Riser 31.8x780mm
Grips
Giant Tactal single lock-on
Seat
Saddle
Giant Sport
Seatpost
Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170)
Motor & Battery
Motor
SyncDrive Sport, 75Nm, powered by Yamaha
Battery
EnergyPak Smart 625, EnergyPak Plus 250Wh range extender compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.454 mm | 1.393 mm | 1.325 mm | 1.267 mm |
| Bottom Bracket Height | 334 mm | 334 mm | 334 mm | 334 mm |
| Front Center | 739 mm | 768 mm | 802 mm | 836 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 124 mm | 124 mm | 124 mm | 124 mm |
| Stack | 618 mm | 627 mm | 636 mm | 646 mm |
| Reach | 425 mm | 450 mm | 480 mm | 510 mm |
| Top Tube Length | 580 mm | 607 mm | 639 mm | 671 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 425 mm | 450 mm | 475 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 468 mm | 468 mm | 468 mm | 468 mm |
| Wheelbase | 1204 mm | 1233 mm | 1267 mm | 1301 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 760 mm | 760 mm | 780 mm | 796 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 170 cm | 178 cm | 186 cm |
| Rider Max Height | 173 cm | 181 cm | 189 cm | 198 cm |
About this model
Stance E+, 1 is a Giant E Stance model. Giant released 29 e-bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Giant Stance E+ EX 2023 has a starting price of 3904$. Giant Stance E+, EX Pro 2023 on the other hand is the most expensive at 5839$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4800$. If we compare this with the average Trail e-bike cost we notice that the price is 42.64% higher.
Overview of components
Fork
Giant Stance E+, 1 2023 e-bike is equipped with the RockShox 35 Silver fork, and has 140mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Stance E+, 1 has a rear shock with a travel of 125mm. The model SR Suntour Raidon R is the one installed in this e-bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on Stance E+, 1 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant Stance E+, 1 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 163 cm – 198 cm (5.35 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
Giant Stance E+, 1 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
