Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
XS
155cm - 168cm
SM
163cm - 174cm
MD
170cm - 181cm
MD/LG
175cm - 187cm
LG
181cm - 193cm
XL
188cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite, Electronic ready
Suspension Fork
Advanced-grade composite, Hybrid OverDrive steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra
Cassette
Shimano Ultegra 11x28, 11-speed
Crank
Shimano Ultegra, 34/50
Bottom Bracket
Shimano, Press Fit
Chain
KMC X11L
Pedals
N/A
Wheels
Front Hub
Giant Performance Tracker Road, Sealed bearing, [F] 24h [R] 28h
Rear Hub
Giant Performance Tracker Road, Sealed bearing, [F] 24h [R] 28h
Rims
Giant PR-2
Spokes
Sapim Race, 14/15g
Tires
Giant P-SL 1, 700x23, Front and rear specific, Folding
Brakes
Brakes
Shimano Ultegra
Brake Levers
Shimano Ultegra
Cockpit
Stem
Giant Connect
Handlebar
Giant Contact, 31.8mm
Seat
Saddle
Giant Performance Road
Seatpost
Giant Variant, Composite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.403 mm | 1.412 mm | 1.45 mm | 1.445 mm | 1.444 mm |
| Stack | 517 mm | 529 mm | 545 mm | 567 mm | 581 mm | 595 mm |
| Reach | 372 mm | 377 mm | 386 mm | 391 mm | 402 mm | 412 mm |
| Top Tube Length | 515 mm | 535 mm | 555 mm | 570 mm | 585 mm | 605 mm |
| Seat Tube Angle | 74.5 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° | 72 ° |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 120 mm | 133 mm | 148 mm | 168 mm | 188 mm | 203 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 972 mm | 974 mm | 980 mm | 986 mm | 1001 mm | 1021 mm |
| Standover Height | 724 mm | 742 mm | 765 mm | 787 mm | 805 mm | 823 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 163 cm | 170 cm | 175 cm | 181 cm | 188 cm |
| Rider Max Height | 168 cm | 174 cm | 181 cm | 187 cm | 193 cm | 200 cm |
About this model
TCR Advanced 1 is part of the Giant Tcr model. There are 260 bikes that carry this model name. You can get a glimpse at all models from 2016, by clicking on this link.
Model range prices
Giant TCR Advanced 3 2016 is the cheapest bike model and costs 1600$. Giant TCR Advanced SL 0 2016 is the most expensive one and costs 8800$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Giant released this model in 2016, its price was 2500$. If we compare this with the average Race bike cost we notice that the price is 34% lower.
TCR Advanced 1 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the TCR Advanced 1 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Giant TCR Advanced 1 is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
TCR Advanced 1 comes in 6 sizes, that range from 155 cm – 200 cm (5.09 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
