Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Apex AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
158cm - 168cm
SM
166cm - 174cm
MD
172cm - 180cm
MD/LG
178cm - 186cm
LG
184cm - 192cm
XL
190cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Advanced-grade composite, 12mm thru-axle, disc
Suspension Fork
Advanced-grade composite, full-composite OverDrive 2 steerer, disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM Apex AXS
Front Derailleur
N/A
Shift Levers
SRAM Apex eTap AXS, 1x12
Cassette
SRAM Rival, 12-speed, 10x36
Crank
SRAM Apex D1 DUB, 40t XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
Bottom Bracket
SRAM DUB, press fit
Chain
SRAM Apex D1
Pedals
N/A
Wheels
Front Hub
[F] Giant alloy, CenterLock, 12mm thru-axle, [R] Giant alloy, 3-pawl 36t driver, CenterLock, 12mm thru-axle
Rear Hub
[F] Giant alloy, CenterLock, 12mm thru-axle, [R] Giant alloy, 3-pawl 36t driver, CenterLock, 12mm thru-axle
Rims
Giant CXR 2 Carbon Disc WheelSystem, [F] 35mm, [R] 35mm
Spokes
Sapim Sprint
Tires
Maxxis All-Terrene, 700x33c, tubeless
Brakes
Brakes
SRAM Apex eTap AXS hydraulic, SRAM PaceLine rotors [F]160mm, [R]140mm
Brake Levers
SRAM Apex AXS hydraulic
Cockpit
Stem
Giant Contact SL XS:70mm, S:80mm, M:90mm, M/L:100mm, L:100mm, XL:110mm
Handlebar
Giant Contact SL XS:40cm, S:40cm, M:42cm, M/L:42cm, L:44cm, XL:44cm
Grips
Stratus Lite 3.0
Seat
Saddle
Giant Approach SL
Seatpost
Giant D-Fuse SLR, composite, -5/+15mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.45 mm | 1.48 mm | 1.48 mm | 1.49 mm | 1.48 mm |
| Bottom Bracket Height | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm | 284 mm |
| Front Center | 583 mm | 591 mm | 597 mm | 607 mm | 617 mm | 632 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 70.3 mm | 68.3 mm | 65.1 mm | 61.8 mm | 58.6 mm | 58.6 mm |
| Stack | 530 mm | 545 mm | 561 mm | 577 mm | 594 mm | 608 mm |
| Reach | 370 mm | 375 mm | 380 mm | 390 mm | 400 mm | 411 mm |
| Top Tube Length | 520 mm | 535 mm | 550 mm | 565 mm | 580 mm | 595 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 505 mm | 525 mm | 545 mm | 555 mm | 565 mm |
| Head Tube Angle | 70.7 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 118 mm | 133 mm | 148 mm | 163 mm | 178 mm | 193 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1011 mm | 1019 mm | 1025 mm | 1035 mm | 1045 mm | 1060 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 780 mm | 793 mm | 812 mm | 831 mm | 837 mm | 850 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 166 cm | 172 cm | 178 cm | 184 cm | 190 cm |
| Rider Max Height | 168 cm | 174 cm | 180 cm | 186 cm | 192 cm | 198 cm |
About this model
TCX, Advanced Pro 1 is a Giant Tcx model. Giant launched 95 bikes of this model so far. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
The most economical model, the Giant TCX, Advanced Pro 1 2024 has a starting price of 3543$. Giant TCX, Advanced Pro 0 2024 on the other hand is the most expensive at 6000$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Cyclocross bikes average price
According to our calculations, the average cost of a Cyclocross bike that is reliable is 2012$. However, you could also get a good Cyclocross bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2024 and its price was 3543$. Comparing this to the average Cyclocross bike price, we see that the price is 76.09% higher.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
As for the wheels, Giant TCX, Advanced Pro 1 2024, has a 700c carbon model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant TCX, Advanced Pro 1 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 6 sizes. They vary from 158 cm – 198 cm (5.18 ft – 6.5 ft). In conclusion, you won’t have a problem finding one that suits you.
