Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Travel Rear 125mm -
Fork Fox Float 32
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum, 5" Maestro Suspension
Suspension Fork
Fox 32 F125RL w/ 15QR Thru-Axle and OverDrive Steerer, 120mm Travel
Rear Shock
Fox FLOAT RP2 Boost Valve
Drivetrain
Rear Derailleur
Shimano Deore XT Shadow, Top Normal
Front Derailleur
Shimano SLX
Shift Levers
Shimano SLX RapidFire, 3x10 Speed
Cassette
Shimano HG81 11x36, 10-Speed
Crank
Shimano M552, 24/32/42
Bottom Bracket
Shimano Press Fit
Chain
Shimano HG-74
Pedals
N/A
Wheels
Front Hub
[F] Giant Tracker Sealed/CNC w/ 15mm Axle, [R] Giant Tracker Performance, 32h
Rear Hub
[F] Giant Tracker Sealed/CNC w/ 15mm Axle, [R] Giant Tracker Performance, 32h
Rims
Giant P-XC2
Spokes
DT Swiss Competition
Tires
Schwalbe Nobby Nic, 26x2.25
Brakes
Brakes
Avid Elixir 5, [F] 185mm, [R] 160mm
Brake Levers
Avid Elixir 5
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect, Low Rise, 31.8
Seat
Saddle
Fi'zi:k Vesta w/ Manganese Rails
Seatpost
Giant Connect, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Top Tube Length | 536 mm | 551 mm | 564 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 124 mm | 135 mm | 150 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1062 mm | 1072 mm | 1087 mm |
| Standover Height | 691 mm | 706 mm | 739 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
Trance X 1 W completes the Giant Trance model. Giant released 139 bikes variations of this model so far. You can easily view all of the Giant Trance bikes models from 2012, here.
Model range prices
Giant Trance X4 2012 is the most economical model, with a starting price of 1550$. Giant Trance X Advanced SL 0 2012 on the other hand costs 8600$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2012 and its price was 2750$. Comparing this to the average Trail bike price, we see that the price is 0.44% smaller.
Trance X 1 W components
Fork
Giant Trance X 1 W 2012 bike is equipped with the Fox Float 32 fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Fox FLOAT RP2 Boost Valve, with a travel distance of 125mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Trance X 1 W are the 26″ aluminum type. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This bike is available in 3 sizes. They vary from 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, it won’t take much to find one that’s right for you.
