Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 125mm -
Fork Fox Float 32
-
Groupset XT -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum, 5" Maestro Suspension
Suspension Fork
Fox 32 Float 29 FIT CTD w/ 15QR thru-axle, OverDrive 2, 120mm Travel
Rear Shock
Fox Float CTD Boostvalve
Drivetrain
Rear Derailleur
Shimano Deore XT Shadow Plus
Front Derailleur
Shimano Deore XT
Shift Levers
Shimano Deore XT, 2x10 Speed
Cassette
Shimano HG81 11x36, 10-Speed
Crank
Shimano Deore XT, 24/38
Bottom Bracket
Shimano, Press Fit
Chain
KMC X10
Pedals
N/A
Wheels
Front Hub
Giant P-TRX 29er 1 WheelSystem
Rear Hub
Giant P-TRX 29er 1 WheelSystem
Rims
Giant P-TRX 29er 1 WheelSystem
Spokes
Giant P-TRX 29er 1 WheelSystem
Tires
Schwalbe Nobby Nic, 29x2.25 TL Ready Evolution Folding
Brakes
Brakes
Shimano Deore XT, [F] 180mm, [R] 160mm
Brake Levers
Shimano Deore XT
Cockpit
Stem
Giant Contact w/ Titanium hardware, OverDrive 2
Handlebar
Giant Contact TR, Low Rise, 31.8
Seat
Saddle
Fi'zi:k Gobi XM w/ Manganese Rails
Seatpost
Giant Contact Switch w/ Remote, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Top Tube Length | 551 mm | 569 mm | 594 mm | 612 mm | 635 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 104 mm | 104 mm | 104 mm | 104 mm | 109 mm |
| Chainstay Length | 452 mm | 452 mm | 452 mm | 452 mm | 452 mm |
| Wheelbase | 1090 mm | 1095 mm | 1120 mm | 1140 mm | 1163 mm |
| Standover Height | 640 mm | 645 mm | 671 mm | 691 mm | 714 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Trance X 29er 0 completes the Giant Trance model. 139 bikes variations carry this model name so far. Take a sneak peek at all Giant Trance bikes models from 2013, by clicking here.
Model range prices
Giant Trance X3 2013 is the cheapest bike model and costs 1550$. Giant Trance X 29er 0 2013 is the most expensive one and costs 4250$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2013 for 4250$. Comparing the average cost of a Trail bike to this one, you will see that Trance X 29er 0 price is 53.87% higher.
Overview of components
Fork
The fork installed on this bike is the Fox Float 32 model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the Fox Float CTD Boostvalve model, with a travel of 125mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the Trance X 29er 0 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Trance X 29er 0 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the Trance X 29er 0. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
