Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Travel Rear 125mm -
Fork RockShox
-
Groupset Deore, Alivio -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum, 5" Maestro Suspension
Suspension Fork
RockShox XC32 TK Coil, OverDrive, 120mm Travel
Rear Shock
Giant Air-R
Drivetrain
Rear Derailleur
Shimano Deore
Front Derailleur
Shimano Alivio
Shift Levers
Shimano Alivio, 3x9 Speed
Cassette
SRAM PG 950 11x34, 9-Speed
Crank
Shimano M542, 22/32/44
Bottom Bracket
Shimano, Press Fit
Chain
KMC X10
Pedals
Alloy Platform
Wheels
Front Hub
[F] Giant Tracker Sealed, [R] Formula Sealed Bearing, 32h
Rear Hub
[F] Giant Tracker Sealed, [R] Formula Sealed Bearing, 32h
Rims
Giant S-XC 2, Double Wall
Spokes
Stainless Steel, 14g
Tires
Schwalbe Nobby Nic, 26x2.25 Performance
Brakes
Brakes
Shimano M395, [F] 180mm, [R] 160mm
Brake Levers
Shimano M395
Cockpit
Stem
Giant Connect
Handlebar
Giant Connect, Low Rise, 31.8
Seat
Saddle
Giant Performance MTB
Seatpost
Giant Connect, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Top Tube Length | 559 mm | 584 mm | 610 mm | 635 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 117 mm | 127 mm | 145 mm | 165 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1082 mm | 1105 mm | 1133 mm | 1158 mm |
| Standover Height | 724 mm | 762 mm | 792 mm | 823 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Trance X3 completes the Giant Trance model. Giant released 139 bikes variations of this model so far. You can get a glimpse at all models from 2013, by clicking on this link.
Model range prices
The most economical model, the Giant Trance X3 2013 has a starting price of 1550$. Giant Trance X 29er 0 2013 on the other hand is the most expensive at 4250$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2013 and its price was 1550$. In conclusion, this bike price is 78.19% smaller than the price of the average Trail bike.
Overview of components
Fork
This bike has the RockShox fork installed. The fork’s travel is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Giant Trance X3 bike has the Giant Air-R model installed, and has a travel of 125mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When leaving the production line, the Trance X3 model has 26″ aluminum wheels. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
For your safety, it is important to have quality breaks on your bike. Giant Trance X3 has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
