Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Lyrik Select+
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
164cm - 179cm
LG
176cm - 187cm
XL
184cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sensor Carbon 29” Frame, 140mm Travel, 12x148mm Thru-Axle, UDH
Suspension Fork
RockShox Lyrik Select + RC2, 150mm, Charger 3, DebonAir+ 44mm Offset
Rear Shock
RockShox Super Deluxe Select + RT, 185x55mm Trunnion
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM NX Eagle, 12-Speed
Cassette
SRAM PG-1230, 11-50T
Crank
Truvativ Descendant 6K, DUB, 32T
Bottom Bracket
SRAM DUB BSA, 73mm
Chain
SRAM NX Eagle, 12-Speed
Pedals
Not included
Wheels
Front Hub
Formula, 15x110mm
Rear Hub
Formula, 12x148mm, HG Freehub Body
Rims
WTB KOM Trail i30, 32h, Tubeless Ready
Tires
Front: Continental Kryptotal Fr, 29x2.4", Enduro Soft, Rear: Continental Kryptotal Fr, 29x2.4", Enduro Soft
Brakes
Brakes
SRAM Code R, 200/180mm Centerline Rotors
Cockpit
Stem
GT Alloy, 45mm
Handlebar
GT Alloy Riser Bar, 30mm Rise, 780mm, 5° Up, 8° Back
Grips
GT Mushroom
Headset
FSA No.42
Seat
Saddle
WTB Silverado
Seatpost
TranzX +Rad, 31.6mm, Adjustable Height (S - 150mm, M - 170mm, L/XL - 200mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.34 mm | 1.27 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 754 mm | 783 mm | 812 mm | 851 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 128 mm | 128 mm | 128 mm | 128 mm |
| Stack | 621 mm | 630 mm | 639 mm | 648 mm |
| Reach | 427 mm | 452 mm | 477 mm | 512 mm |
| Top Tube Length | 571 mm | 598 mm | 625 mm | 663 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 380 mm | 400 mm | 420 mm | 460 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1188 mm | 1218 mm | 1247 mm | 1286 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 712 mm | 722 mm | 732 mm | 742 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 164 cm | 176 cm | 184 cm |
| Rider Max Height | 167 cm | 179 cm | 187 cm | 198 cm |
Model Overview
Sensor Carbon Pro is a Gt Sensor model. 38 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
GT Sensor Sport 2023 is the cheapest bike model and costs 2300$. GT Sensor Carbon Pro LE 2023 is the most expensive one and costs 5750$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, GT Sensor Carbon Pro price was 4950$. Comparing this to the average Trail bike price, we see that the price is 79.22% higher.
Sensor Carbon Pro components
Fork
The fork installed on this bike is the RockShox Lyrik Select+ model. The travel on this model is 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this bike has the RockShox Super Deluxe Select + RT model, with a travel of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When it comes to wheels, the Sensor Carbon Pro bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. GT Sensor Carbon Pro is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 152 cm – 198 cm (4.99 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
GT Sensor Carbon Pro comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
