Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 120mm -
Fork RockShox Pike Select+
-
Groupset GX Eagle, NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
164cm - 179cm
LG
176cm - 187cm
XL
184cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sensor ST Carbon 29” Frame, 120mm Travel, 12x148mm Thru-Axle, UDH
Suspension Fork
RockShox Pike Select + RC2, 140mm, Charger 3, DebonAir+, 44mm Offset
Rear Shock
RockShox Deluxe Select + RT, 185x47.5mm Trunnion
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM NX Eagle, 12-Speed
Cassette
SRAM PG-1230, 11-50T
Crank
Truvativ Stylo 6K, DUB, 32T
Bottom Bracket
SRAM DUB BSA, 73mm
Chain
SRAM NX Eagle, 12-Speed
Wheels
Front Hub
Formula, 15x110mm
Rear Hub
Formula, 12x148mm, HG Freehub Body
Rims
WTB KOM Trail i27, 32h, Tubeless Ready
Tires
Front: Maxxis Dissector, 29x2.4", 3C MaxxTerra, EXO, Rear: Maxxis Dissector, 29x2.4", 3C MaxxTerra, EXO
Brakes
Brakes
SRAM G2 RSC, 180/180mm Centerline Rotors
Cockpit
Stem
GT Alloy, 45mm
Handlebar
GT Alloy Riser Bar, 20mm Rise, 780mm, 5° Up, 8° Back
Grips
GT Mushroom
Headset
FSA No.42
Seat
Saddle
WTB Silverado
Seatpost
GT DropKick, 31.6mm, (S - 125mm, M - 150mm, L/XL - 170mm)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.37 mm | 1.32 mm | 1.25 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 750 mm | 779 mm | 808 mm | 848 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 125 mm | 125 mm | 125 mm | 125 mm |
| Stack | 618 mm | 626 mm | 635 mm | 644 mm |
| Reach | 432 mm | 457 mm | 482 mm | 517 mm |
| Top Tube Length | 570 mm | 597 mm | 624 mm | 661 mm |
| Seat Tube Angle | 77.4 ° | 77.4 ° | 77.4 ° | 77.4 ° |
| Seat Tube Length | 380 mm | 400 mm | 420 mm | 460 mm |
| Head Tube Angle | 65.4 ° | 65.4 ° | 65.4 ° | 65.4 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1184 mm | 1213 mm | 1243 mm | 1282 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 708 mm | 718 mm | 728 mm | 738 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 164 cm | 176 cm | 184 cm |
| Rider Max Height | 167 cm | 179 cm | 187 cm | 198 cm |
About this model
Sensor ST Carbon Pro completes the Gt Sensor model. There are 38 bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
GT Sensor Sport 2023 is the cheapest bike model and costs 2300$. GT Sensor Carbon Pro LE 2023 is the most expensive one and costs 5750$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, GT Sensor ST Carbon Pro price was 5000$. In conclusion, this bike price is 81.03% higher than the price of the average Trail bike.
Overview of components
Fork
The RockShox Pike Select+ is included from the factory. It has a travel distance of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
GT Sensor ST Carbon Pro bike has the RockShox Deluxe Select + RT model installed, and has a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The Sensor ST Carbon Pro 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sensor ST Carbon Pro comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Sensor ST Carbon Pro comes in 4 sizes, that range from 152 cm – 198 cm (4.99 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the Sensor ST Carbon Pro. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
