Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 160mm -
Fork Fox Factory Float 38
-
Groupset XT -
Suspension Full -
Motor Yamaha 85Nm mid-drive -
Battery InTube, 750 Wh -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, AllMtn PW-X3, Aluminium
Suspension Fork
FOX, 38 Factory Kashima, Air, 160 mm
Rear Shock
FOX, Float X Factory EVOL LV, Air, Trunnion
Drivetrain
Rear Derailleur
Shimano, Deore XT M8100 Shadow Plus
Shift Levers
Shimano, Deore XT M8100, Trigger switch
Cassette
Shimano, M6100, 10 - 51 teeth
Crank
Haibike Components, Aluminium, 36 teeth
Bottom Bracket
integrated in the motor
Chain
Shimano, SLX M7100
Chain Guide
Nylon directmount
Pedals
Freeridepedal, Aluminium, with Reflector
Wheels
Rims
Mavic, E-Deemax
Tires
Maxxis, Minion DHF II, 63-622, 29 x 2.5 inch
Brakes
Brakes
hydraulicDisc
Brake Levers
Shimano, Deore XT M8100, Aluminium
Cockpit
Stem
Haibike Components, TheStem +++, 31.8 mm
Handlebar
Haibike Components, TheBar +++, 780 mm
Grips
Haibike, MTB grips
Headset
Acros, BlockLock, Aluminium
Seat
Saddle
fi'zi:k, Terra Aidon X5-160
Seatpost
Haibike Components, Dropper-Post Remote 34.9, Aluminium, Telescope, 34.9 mm
Motor & Battery
Motor
Yamaha, PW-X3, 250 Wh, 85 Nm
Battery
InTube, 750 Wh
Remote
Yamaha, Interface - X
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.534 mm | 1.432 mm | 1.379 mm | 1.315 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 761 mm | 791 mm | 820 mm | 854 mm |
| Rake | 37 mm | 37 mm | 38 mm | 37 mm |
| Trail | 138 mm | 138 mm | 137 mm | 138 mm |
| Stack | 646 mm | 646 mm | 655 mm | 664 mm |
| Reach | 421 mm | 451 mm | 475 mm | 505 mm |
| Top Tube Length | 570 mm | 600 mm | 627 mm | 659 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1220 mm | 1250 mm | 1279 mm | 1313 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
AllMtn 10 completes the Haibike E Allmtn model. There are 24 e-bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Haibike AllMtn 1 2022 is the most affordable e-bike of this model and has a price of 4989$. On the other hand, Haibike AllMtn CF SE 2022, is the most expensive and costs 9343$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2022 and its price was 7219$. Comparing this to the average Enduro e-bike price, we see that the price is 50.87% more expensive.
Overview of components
Fork
This e-bike has the Fox Factory Float 38 fork installed. The fork’s travel is 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The wheels on AllMtn 10 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The AllMtn 10 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Haibike AllMtn 10 includes a dropper post. Therefore, climbing or descending will be a breeze.
