Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 160mm -
Fork RockShox 35 Gold RL
-
Groupset SX Eagle, SRAM -
Suspension Full -
Motor Yamaha 85Nm mid-drive -
Battery InTube, 630 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, AllMtn PW-X3, Aluminium
Suspension Fork
RockShox, 35 Gold RL, Air, 160 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Rear Shock
RockShox, Deluxe Select Plus, Air, Trunnion Mount
Drivetrain
Rear Derailleur
SRAM, SX Eagle
Shift Levers
SRAM, SX Eagle, Trigger switch
Cassette
SRAM, Eagle PG1210, 11 - 50 teeth
Crank
SRAM, 38 teeth
Bottom Bracket
integrated in the motor
Chain
SRAM, SX Eagle
Chain Guide
Nylon directmount
Pedals
Freeridepedal, Aluminium, with Reflector
Wheels
Rims
WTB, ST i30 TCS, Double Wall
Spokes
Sapim, Race
Tires
Maxxis, Minion DHF II, 63-622, 29 x 2.5 inch
Brakes
Brakes
hydraulicDisc
Brake Levers
TRP, Slate T4, Aluminium
Cockpit
Stem
Haibike Components, TheStem +++, 31.8 mm
Handlebar
Haibike Components, TheBar +++, 780 mm
Grips
Haibike, MTB grips
Headset
Acros, BlockLock, Aluminium
Seat
Saddle
Selle Royal, Vivo
Seatpost
Haibike Components, Dropper-Post Remote 34.9, Aluminium, Telescope, 34.9 mm
Motor & Battery
Motor
Yamaha, PW-X3, 250 Wh, 85 Nm
Battery
InTube, 630 Wh
Remote
Yamaha, Side Switch, 1.7" LCD, 7 functions
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.534 mm | 1.432 mm | 1.379 mm | 1.315 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 761 mm | 791 mm | 820 mm | 854 mm |
| Rake | 37 mm | 37 mm | 38 mm | 37 mm |
| Trail | 138 mm | 138 mm | 137 mm | 138 mm |
| Stack | 646 mm | 646 mm | 655 mm | 664 mm |
| Reach | 421 mm | 451 mm | 475 mm | 505 mm |
| Top Tube Length | 570 mm | 600 mm | 627 mm | 659 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1220 mm | 1250 mm | 1279 mm | 1313 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
AllMtn 2 is a Haibike E Allmtn model. Haibike launched 24 e-bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Haibike AllMtn 1 2022 is the cheapest e-bike model and costs 4989$. Haibike AllMtn CF SE 2022 is the most expensive one and costs 9343$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Enduro e-bikes average price
If you want to purchase a solid Enduro e-bike, it is important to know that the average cost is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2022 and its price was 5308$. Comparing the average cost of an Enduro e-bike to this one, you will see that AllMtn 2 price is 10.93% more expensive.
AllMtn 2 components
Fork
The RockShox 35 Gold RL is included from the factory. It has a travel distance of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the e-bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The wheels on AllMtn 2 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The AllMtn 2 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the AllMtn 2. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
