Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" / 27.5" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Yari RC
-
Groupset SX Eagle -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube, integrated -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Yari RC, air spring, lockout
Rear Shock
RockShox Deluxe RT, air spring
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM SX Eagle PG-1210, 12-speed, 11-50 tooth
Crank
Haibike, forged aluminum
Chain
SRAM SX Eagle, 12-speed
Chain Guide
Upper slider
Pedals
MTB platform, aluminum
Wheels
Front Hub
Shimano MT400, 110mm Boost front, 12x148mm Boost rear with HG driver
Rear Hub
Shimano MT400, 110mm Boost front, 12x148mm Boost rear with HG driver
Rims
Alexrims MD30, double-walled aluminum, 32 hole
Spokes
Stainless steel
Tires
Front: Maxxis Minion DHF, 29" x 2.5", Rear: Maxxis Minion DHR II, 27.5" x 2.8"
Brakes
Brakes
Shimano MT420, 4-piston, CENTER LOCK rotors (203mm front, 180mm rear)
Brake Levers
Shimano MT401
Cockpit
Stem
Haibike Components The Stem 2, 31.8mm bar clamp
Handlebar
Haibike Components The Bar, 780mm width, 31.8mm clamp diameter
Grips
Haibike MTB
Headset
A-Head, tapered
Seat
Saddle
Selle Royale Vivo
Seatpost
XLC dropper
Motor & Battery
Motor
Bosch Gen4 Performance CX, 250W, 75Nm max torque
Battery
Bosch PowerTube, integrated
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.45 mm | 1.38 mm | 1.32 mm |
| Stack | 614 mm | 618 mm | 623 mm | 628 mm |
| Reach | 402 mm | 426 mm | 450 mm | 474 mm |
| Top Tube Length | 568 mm | 593 mm | 618 mm | 643 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 120 mm | 125 mm | 130 mm | 135 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1176 mm | 1197 mm | 1218 mm | 1239 mm |
| Standover Height | 783 mm | 793 mm | 808 mm | 828 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
AllMtn 3 is part of the Haibike E Allmtn model. There are 24 e-bikes that carry this model name. Take a sneak peek at all Haibike E Allmtn e-bikes models from 2021, by clicking here.
Model range prices
Haibike AllMtn 2 2021 is the most economical model, with a starting price of 4777$. Haibike AllMtn SE 2021 on the other hand costs 10618$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Haibike AllMtn 3 price was 5750$. Comparing the average cost of an Enduro e-bike to this one, you will see that AllMtn 3 price is 20.17% higher.
Overview of components
Fork
The AllMtn 3 comes factory-installed with the RockShox Yari RC fork. This has a travel range of 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this e-bike has the RockShox Deluxe RT model, with a travel of 150mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The AllMtn 3 2021 e-bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The AllMtn 3 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Haibike AllMtn 3 e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the AllMtn 3. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
