Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 65mm -
Fork Fox Performance Float 38
-
Groupset GX Eagle, SRAM -
Suspension Full -
Motor Yamaha 250W 80Nm mid-drive -
Battery Yamaha, 600 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, XDURO AllMtn i600, Carbon
Suspension Fork
FOX, 38 Performance, Air/oil, Travel= 160 mm, Aluschaft 1 1/8 - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Rear Shock
FOX, Float DPS Performance EVOL, Air, 65.0 mm, 25 x 8mm 25 x 8mm
Drivetrain
Rear Derailleur
SRAM, GX Eagle
Shift Levers
SRAM, GX Eagle, Trigger switch, 12 Speed
Cassette
SRAM, Eagle PG1230, 11 - 50 teeth
Crank
SRAM, X-Sync 2 Eagle, 38 teeth
Bottom Bracket
Integrated in the motor
Chain
SRAM, SX Eagle
Pedals
Freeridepedal, Aluminium, with Reflector,
Wheels
Rims
Mavic, E-XM 430
Spokes
Sapim, Leader, Black
Tires
Maxxis, Minion DHF II, 63-622, 29" x 2.5"
Brakes
Brakes
hydraulicDisc
Brake Levers
Magura, MT5 HC-lever, Aluminium
Cockpit
Stem
Haibike Components, TheStem 2, A-head, Bar bore: 31.8 mm
Handlebar
Haibike Components, TheBar +++ Gravity, 780 mm
Grips
Haibike, MTB grips
Headset
Acros, BlockLock, Aluminium
Seat
Saddle
Selle Royal Vivo 1216HRN
Seatpost
Haibike Components, Dropper-Post Remote 31.6, Aluminium, Telescope
Motor & Battery
Motor
Yamaha, PW-X2, 250W, 80 Nm, 25 km/h
Battery
Yamaha, 600 Wh
Remote
Yamaha, Side Switch, 1.7" LCD, 7 functions
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.493 mm | 1.388 mm | 1.352 mm | 1.268 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 736 mm | 766 mm | 799 mm | 829 mm |
| Rake | 60 mm | 60 mm | 60 mm | 60 mm |
| Trail | 108 mm | 108 mm | 108 mm | 108 mm |
| Stack | 597 mm | 597 mm | 615 mm | 615 mm |
| Reach | 400 mm | 430 mm | 455 mm | 485 mm |
| Top Tube Length | 560 mm | 590 mm | 620 mm | 650 |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 110 mm | 130 mm | 130 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1195 mm | 1225 mm | 1258 mm | 1288 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
AllMtn 6 belongs to the Haibike E Allmtn model. 24 e-bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Haibike AllMtn 2 2021 is the most economical model, with a starting price of 4777$. Haibike AllMtn SE 2021 on the other hand costs 10618$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry e-bikes
According to our calculations, the average cost of a Crosscountry e-bike that is reliable is 2453$. However, you could also get a good Crosscountry e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2021 for 6370$. Comparing this to the average Crosscountry e-bike price, we see that the price is 159.68% higher.
Overview of components
Fork
The fork installed on this bike is the Fox Performance Float 38 model. The travel on this model is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this e-bike is FOX, with a travel distance of 65mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
As for the wheels, Haibike AllMtn 6 2021, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Haibike AllMtn 6 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
AllMtn 6 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the AllMtn 6. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
