Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Fork Fox Factory Float 38
-
Groupset XT -
Suspension Full -
Motor Yamaha 250W 80Nm mid-drive -
Battery Yamaha, 600 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, XDURO AllMtn i600, Carbon
Suspension Fork
FOX, 38 Factory Kashima, Air, Travel= 160 mm
Rear Shock
FOX, DPX2 Factory Kashima, Air, Trunnion Mount M8x30
Drivetrain
Rear Derailleur
Shimano, Deore XT M8100 Shadow Plus
Shift Levers
Shimano, Deore XT M8100, Trigger switch, 12 Speed
Cassette
Shimano, SLX M7100, 10 - 51 teeth
Crank
Haibike Components, Aluminium, 38 teeth
Bottom Bracket
Integrated in the motor
Chain
Shimano, SLX M7100
Pedals
Freeridepedal, Aluminium, with Reflector,
Wheels
Rims
Syntace, V30i, with eyelets, hollow rim, Aluminium
Spokes
Syntace, Straight Pull butted
Tires
Maxxis, Minion DHF II, 63-622, 29" x 2.5"
Brakes
Brakes
hydraulicDisc
Brake Levers
Shimano, Deore XT M8100, Aluminium
Cockpit
Stem
Haibike Components, TheStem 2, A-head, Bar bore: 31.8 mm
Handlebar
Haibike Components, TheBar +++ Gravity, 780 mm
Grips
Haibike, MTB grips
Headset
Acros, BlockLock, Aluminium
Seat
Saddle
Selle Royal Vivo 1216HRN
Seatpost
Haibike Components, Dropper-Post Remote 31.6, Aluminium, Telescope
Motor & Battery
Motor
Yamaha, PW-X2, 250W, 80 Nm, 25 km/h
Battery
Yamaha, 600 Wh
Remote
Yamaha, Side Switch, 1.7" LCD, 7 functions
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.493 mm | 1.388 mm | 1.352 mm | 1.268 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 736 mm | 766 mm | 799 mm | 829 mm |
| Rake | 60 mm | 60 mm | 60 mm | 60 mm |
| Trail | 108 mm | 108 mm | 108 mm | 108 mm |
| Stack | 597 mm | 597 mm | 615 mm | 615 mm |
| Reach | 400 mm | 430 mm | 455 mm | 485 mm |
| Top Tube Length | 560 mm | 590 mm | 620 mm | 650 |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 110 mm | 130 mm | 130 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1195 mm | 1225 mm | 1258 mm | 1288 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
AllMtn 7 belongs to the Haibike E Allmtn model. Haibike released 24 e-bikes variations of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Haibike AllMtn 2 2021 is the most economical model, with a starting price of 4777$. Haibike AllMtn SE 2021 on the other hand costs 10618$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro e-bikes
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, even though the average price of an Enduro e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
When Haibike released this model in 2021, its price was 6901$. If we compare this with the average Enduro e-bike cost we notice that the price is 44.22% more expensive.
Overview of components
Fork
Haibike AllMtn 7 2021 e-bike is equipped with the Fox Factory Float 38 fork, and has 160mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on AllMtn 7 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Haibike AllMtn 7 e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Haibike model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
