Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 160mm -
Fork Fox Performance Float 36
-
Groupset GX Eagle, SRAM -
Suspension Full -
Motor Yamaha 85Nm mid-drive -
Battery InTube, 750 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, AllMtn PW-X3, Aluminium
Suspension Fork
FOX, 36 Float Performance Luft 160, Lockout, Air, 160 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Rear Shock
FOX, Float DPS Performance EVOL LV Trunnion, Air, Trunnion
Drivetrain
Rear Derailleur
SRAM, GX Eagle
Shift Levers
SRAM, CX Eagle, Trigger switch
Cassette
SRAM, Eagle PG1230, 11 - 50 teeth
Crank
SRAM, 38 teeth
Bottom Bracket
integrated in the motor
Chain
SRAM, SX Eagle
Chain Guide
Nylon directmount
Pedals
Freeridepedal, Aluminium, with Reflector
Wheels
Rims
WTB, ST i30 TCS, Double Wall
Spokes
Sapim, Race
Tires
Maxxis, Minion DHF II, 63-622, 29 x 2.5 inch
Brakes
Brakes
hydraulicDisc
Brake Levers
Magura, MT7 HC-lever
Cockpit
Stem
Haibike Components, TheStem +++, 31.8 mm
Handlebar
Haibike Components, TheBar +++, 780 mm
Grips
Haibike, MTB grips
Headset
Acros, BlockLock, Aluminium
Seat
Saddle
fi'zi:k, Terra Aidon X5-160
Seatpost
Haibike Components, Dropper-Post Remote 34.9, Aluminium, Telescope, 34.9 mm
Motor & Battery
Motor
Yamaha, PW-X3, 250 Wh, 85 Nm
Battery
InTube, 750 Wh
Remote
Yamaha, Interface - X
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.534 mm | 1.432 mm | 1.379 mm | 1.315 mm |
| Bottom Bracket Height | 354 mm | 354 mm | 354 mm | 354 mm |
| Front Center | 761 mm | 791 mm | 820 mm | 854 mm |
| Rake | 37 mm | 37 mm | 38 mm | 37 mm |
| Trail | 138 mm | 138 mm | 137 mm | 138 mm |
| Stack | 646 mm | 646 mm | 655 mm | 664 mm |
| Reach | 421 mm | 451 mm | 475 mm | 505 mm |
| Top Tube Length | 570 mm | 600 mm | 627 mm | 659 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1220 mm | 1250 mm | 1279 mm | 1313 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
AllMtn 7 completes the Haibike E Allmtn model. There are 24 e-bikes that carry this model name. Take a sneak peek at all Haibike E Allmtn e-bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Haibike AllMtn 1 2022 has a starting price of 4989$. Haibike AllMtn CF SE 2022 on the other hand is the most expensive at 9343$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Enduro e-bikes average price
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2022 and its price was 6370$. Comparing this to the average Enduro e-bike price, we see that the price is 33.12% more expensive.
Overview of components
Fork
The AllMtn 7 comes factory-installed with the Fox Performance Float 36 fork. This has a travel range of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
AllMtn 7 has an aluminum fork, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Wheels
As for the wheels, Haibike AllMtn 7 2022, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
AllMtn 7 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Haibike AllMtn 7 comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
