Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 140mm -
Travel Rear 60mm -
Fork RockShox Pike Select
-
Groupset SLX, Deore -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch, PowerTube, 625 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, FullNine Bosch i625, Aluminium 6061
Suspension Fork
RockShox, Pike Select RC, Air/oil, Travel= 140 mm, Aluschaft 1 1/8 - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Rear Shock
RockShox, Deluxe Select Plus, Air, 60.0 mm, Trunnion Mount M8x30
Drivetrain
Rear Derailleur
Shimano, SLX M7100
Shift Levers
Shimano, Deore M6100, Trigger switch, 12 Speed
Cassette
Shimano, M6100, 10 - 51 teeth
Crank
Haibike Components, Aluminium, 38 teeth
Bottom Bracket
Integrated in the motor
Chain
Shimano, CN-M6100
Chain Guide
Nylon dircetmount
Pedals
Freeridepedal, Aluminium, with Reflector,
Wheels
Rims
Rodi, Tryp 30, with eyelets, hollow rim, Aluminium
Spokes
Sapim, Leader, Black
Tires
Schwalbe, Nobby Nic Evo Super Trail, 65-622, 29" x 2.6"
Brakes
Brakes
hydraulicDisc
Brake Levers
Magura, MT5 HC-lever, Aluminium
Cockpit
Stem
Haibike Components, TheStem 2, A-head, Bar bore: 31.8 mm
Handlebar
Haibike Components, TheBar +++ Gravity, 780 mm
Grips
Haibike, MTB grips
Headset
Feimin, A-Head Tapered, Aluminium, Cartridge
Seat
Saddle
Selle Royal Vivo 1216HRN
Seatpost
Haibike Components, TheSeatpost ++, Aluminium, 31.6 mm
Motor & Battery
Motor
Bosch, Performance CX GEN4, 250W, 85 Nm, 25 km/h
Battery
Bosch, PowerTube, 625 Wh
Remote
Bosch, Purion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.527 mm | 1.512 mm | 1.475 mm | 1.409 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 724 mm | 738 mm | 765 mm | 800 mm |
| Rake | 43 mm | 43 mm | 44 mm | 43 mm |
| Trail | 120 mm | 120 mm | 119 mm | 120 mm |
| Stack | 626 mm | 635 mm | 649 mm | 662 mm |
| Reach | 410 mm | 420 mm | 440 mm | 470 mm |
| Top Tube Length | 563 mm | 576 mm | 599 mm | 633 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 477 mm | 477 mm | 477 mm | 477 mm |
| Wheelbase | 1199 mm | 1213 mm | 1240 mm | 1275 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
FullNine 9 belongs to the Haibike E Fullnine model. Haibike launched 7 e-bikes of this model so far. You can easily view all of the Haibike E Fullnine e-bikes models from 2021, here.
Model range prices
Haibike FullNine 4 2021 is the cheapest e-bike model and costs 3715$. Haibike FullNine 10 2021 is the most expensive one and costs 6370$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry e-bikes
If you want to purchase a solid Crosscountry e-bike, it is important to know that the average cost is 2453$. However, this doesn’t mean that if you spend less money on a Crosscountry e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
When Haibike released this model in 2021, its price was 5626$. In conclusion, this e-bike price is 129.35% more expensive than the price of the average Crosscountry e-bike.
FullNine 9 components
Fork
Haibike FullNine 9 2021 e-bike is equipped with the RockShox Pike Select fork, and has 140mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the RockShox rear shock model, which has a travel of 60mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the FullNine 9 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The FullNine 9 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
