Haibike HardSeven 5 2022
2022 E-bike
Estimate price |
3,325$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset Alivio -
Suspension Hardtail -
Motor Bosch 250W 65Nm mid-drive -
Battery Bosch, PowerTube, 500 Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, HardSeven Gen3 Intube, Aluminium 6061
Suspension Fork
SR Suntour, XCM32 Boost DS, Steel spring/oil, Travel= 120 mm, Aluschaft 1 1/8 - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Drivetrain
Rear Derailleur
Shimano, Alivio M3100
Shift Levers
Shimano, Alivio M3100, Trigger switch, 9 Speed
Cassette
Shimano, HG200, 11 - 36 teeth
Crank
Steel, 38 teeth
Bottom Bracket
Integrated in the motor
Chain
KMC, e9S
Pedals
Freeridepedal, Aluminium, with Reflector,
Wheels
Rims
Schürmann, Yak25, with eyelets, hollow rim, Aluminium
Spokes
Sapim, Leader, Black
Tires
WTB, Ranger Comp, 55-584, 27.5" x 2.30"
Brakes
Brakes
Hydraulic Disc
Brake Levers
Tektro, M275, Aluminium
Cockpit
Stem
XLC, Alu, A-head
Handlebar
XLC, Topflat, 720 mm
Grips
Haibike, MTB grips
Headset
Feimin, A-Head Tapered, Ball bearing
Seat
Saddle
XLC, MTB
Seatpost
XLC, Aluminium, Patent, 31.6 mm
Motor & Battery
Motor
Bosch, Performance Line, 250W, 65 Nm, 25 km/h
Battery
Bosch, PowerTube, 500 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.541 mm | 1.449 mm | 1.435 mm |
| Bottom Bracket Height | 301 mm | 301 mm | 306 mm |
| Front Center | 732 mm | 768 mm | 805 mm |
| Rake | 54 mm | 53 mm | 53 mm |
| Trail | 106 mm | 107 mm | 107 mm |
| Stack | 624 mm | 633 mm | 660 mm |
| Reach | 405 mm | 437 mm | 460 mm |
| Top Tube Length | 574 mm | 610 mm | 640 mm |
| Seat Tube Angle | 74.8 ° | 74.7 ° | 74.7 ° |
| Seat Tube Length | 400 mm | 460 mm | 490 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 125 mm | 135 mm | 170 mm |
| Chainstay Length | 490 mm | 490 mm | 490 mm |
| Wheelbase | 1217 mm | 1253 mm | 1291 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 49 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
HardSeven 5 is part of the Haibike E Hardseven model. Haibike released 10 e-bikes variations of this model so far. Take a sneak peek at all Haibike E Hardseven e-bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Haibike HardSeven 5 2022 has a starting price of 3078$. Haibike HardSeven 7 2022 on the other hand is the most expensive at 3821$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2022 and its price was 3078$. In conclusion, this e-bike price is 9.32% smaller than the price of the average Trail e-bike.
Overview of components
Fork
The fork installed on this bike is the Suntour XCM model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork on this e-bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
The wheels on HardSeven 5 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Haibike HardSeven 5 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
