Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Travel Front 180mm -
Fork RockShox Domain
-
Groupset SX Eagle, SRAM -
Suspension Full -
Motor Yamaha 85Nm mid-drive -
Battery InTube, 630 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Haibike, Nduro PW-X3, Aluminium
Suspension Fork
RockShox, Domain R, Air, 180 mm travel, Aluminium steerer tube 1 1/8" - 1 1/2" tapered, 15 x 110mm thru-axle Boost
Rear Shock
RockShox, Super Deluxe Select, Air, Trunnion
Drivetrain
Rear Derailleur
SRAM, SX Eagle
Shift Levers
SRAM, SX Eagle, Trigger switch
Cassette
SRAM, Eagle PG1230, 11 - 50 teeth
Crank
SRAM, 38 teeth
Bottom Bracket
integrated in the motor
Chain
SRAM, SX Eagle
Chain Guide
Nylon directmount
Pedals
Freeridepedal, Aluminium, with Reflector
Wheels
Rims
WTB, ST i30 TCS, Double Wall
Spokes
Sapim, Race
Tires
Schwalbe, Magic Mary Evo TLE, 29 x 2.4 inch
Brakes
Brakes
hydraulicDisc
Brake Levers
TRP, Slate G-Spec, Aluminium, Adjustable
Cockpit
Stem
Haibike Components, TheStem 2, A-head, 31.8 mm
Handlebar
Haibike Components, TheBar +++, 780 mm
Grips
Haibike, MTB grips
Headset
Acros, BlockLock, Aluminium
Seat
Saddle
Selle Royal, Vivo
Seatpost
Haibike Components, Dropper-Post Remote 34.9, Aluminium, Telescope, 34.9 mm
Motor & Battery
Motor
Yamaha, PW-X3, 250 Wh, 85 Nm
Battery
InTube, 630 Wh
Remote
Yamaha, Side Switch, 1.7" LCD, 7 functions
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.515 mm | 1.415 mm | 1.36 mm | 1.298 mm |
| Bottom Bracket Height | 369 mm | 369 mm | 369 mm | 369 mm |
| Front Center | 785 mm | 815 mm | 845 mm | 879 mm |
| Rake | 37 mm | 37 mm | 38 mm | 37 mm |
| Trail | 145 mm | 145 mm | 144 mm | 145 mm |
| Stack | 644 mm | 644 mm | 653 mm | 662 mm |
| Reach | 425 mm | 455 mm | 480 mm | 510 mm |
| Top Tube Length | 574 mm | 604 mm | 631 mm | 663 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1245 mm | 1275 mm | 1305 mm | 1339 mm |
| Bottom Bracket Drop | 5 mm | 5 mm | 5 mm | 5 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Nduro 6 is part of the Haibike E Nduro model. There are 3 e-bikes that carry this model name. You can easily view all of the Haibike E Nduro e-bikes models from 2022, here.
Model range prices
Haibike Nduro 6 2022 is the cheapest e-bike model and costs 5626$. Haibike Nduro 8 Freeride 2022 is the most expensive one and costs 7750$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Enduro e-bikes average price
According to our calculations, the average cost of an Enduro e-bike that is reliable is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5626$. In conclusion, this e-bike price is 17.58% more expensive than the price of the average Enduro e-bike.
Nduro 6 components
Fork
This e-bike has the RockShox Domain fork installed. The fork’s travel is 180mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
Nduro 6 has an aluminum fork, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Haibike Nduro 6 2022, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
A dropper post is included with the Nduro 6. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
