Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 130mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, FSA -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 series alloy dual suspended 4-Bar linkage frame, 27.5" Plus / 29" geometry, 130mm rear travel, tapered 1.5" head tube, 73mm BB shell, Enduro bearings, 12x148mm Boost thru-axle dropouts
Suspension Fork
New Rockshox Recon RL 29" B Boost; 1-1/8 - 1.5" tapered alloy steerer, 130mm travel, Solo Air, 15x110mm Maxle Lite thru-axle
Rear Shock
New RockShox Monarch R Solo Air 190X51, MM tune
Drivetrain
Rear Derailleur
Shimano Deore RD-M6000, 10-spd, Top Normal, Shadow Plus design
Front Derailleur
GW alloy chain guide, Front Der. plate mounted
Shift Levers
Shimano Deore M6000, Right only, 1x10-spd, w/ optical gear display
Cassette
Shimano CS-HG500-10 11-42T, 10-Speed
Crank
FSA Comet Modular w/ 30T Megatooth Crmo Chainring
Bottom Bracket
FSA MegaExo 73mm Boost sealed cartridge
Chain
KMC X10 NP/GY, w/ Missing Link
Chain Guide
GW alloy, front derailleur plate mounted
Pedals
N/A
Wheels
Front Hub
Pivit Boost alloy sealed bearing disc hubs, 32h, Thru axles: 15mm Front & 12mm Rear
Rear Hub
Pivit Boost alloy sealed bearing disc hubs, 32h, Thru axles: 15mm Front & 12mm Rear
Rims
WTB ST i35 27.5" Plus rims, 40mm wide, alloy double wall, w/ TCS i35 rim tape
Tires
Kenda Havoc 27.5x2.6", 60 TPI
Brakes
Brakes
MY19 Shimano BR-MT400 hydraulic, 180/160mm rotors
Brake Levers
Shimano BL-MT400
Cockpit
Stem
Pivit alloy Trail 0 Deg. 4 bolts, ext.: 60mm
Handlebar
Pivit alloy 12mm riser bar 31.8mm, 760mm, 9 Deg. sweep
Grips
WTB Ace, dual clamps, 135mm
Headset
FPD DOZER-1160A-2 w/ 1.5" ACB bottom for 44/56mm head tube, w/ 8mm Top Cone
Seat
Saddle
WTB Volt Sport w/ color accents
Seatpost
X-Fusion Manic 125 Dropper post w/ shifter-type remote, 7075 alloy, 31.6x125mmx400 / 100x360mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.6 mm | 1.5 mm | 1.41 mm | 1.38 mm |
| Bottom Bracket Height | 315 mm | 315 mm | 315 mm | 315 mm |
| Front Center | 666 mm | 688 mm | 725 mm | 745 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 99 mm | 95 mm | 94 mm | 94 mm |
| Stack | 611 mm | 613 mm | 623 mm | 632 mm |
| Reach | 382 mm | 409 mm | 441 mm | 458 mm |
| Top Tube Length | 567 mm | 587 mm | 617 mm | 632 mm |
| Seat Tube Angle | 70.5 ° | 71.5 ° | 72.2 ° | 72.8 ° |
| Seat Tube Length | 368 mm | 406 mm | 457 mm | 520 mm |
| Head Tube Angle | 67.5 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 459 mm | 459 mm | 459 mm | 459 mm |
| Wheelbase | 1122 mm | 1144 mm | 1181 mm | 1201 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 745 mm | 746 mm | 762 mm | 765 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Shift R5 Plus completes the Haro Shift model. Haro released 31 bikes variations of this model so far. Take a sneak peek at all Haro Shift bikes models from 2019, by clicking here.
Model range prices
Haro Shift S3 29 2019 is the cheapest bike model and costs 1299$. Haro Shift R9 Plus 2019 is the most expensive one and costs 2988$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Haro Shift R5 Plus price was 2149$. If we compare this with the average Trail bike cost we notice that the price is 28.52% lower.
Shift R5 Plus components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
The Shift R5 Plus has a rear shock with a travel of 130mm. The model New RockShox Monarch R Solo Air 190X51 is the one installed in this bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Haro Shift R5 Plus 2019, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Haro Shift R5 Plus bike has 4 sizes, in the range of 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
